ABB 1SDA123748R1 AUX 6Q 400Vac E2.2...E6.2 W Air Circuit Breaker Accessory

% $-124.05
ABB 1SDA123748R1 AUX 6Q changeover contact block, 400V AC, for Emax 2 E2.2-E6.2 W
ABB 1SDA123748R1 AUX 6Q changeover contact block, 400V AC, for Emax 2 E2.2-E6.2 W

ABB 1SDA123748R1 AUX 6Q 400Vac E2.2...E6.2 W Air Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA123748R1
Catalog No: AUX 6Q 400Vac E2.2...E6.2 W
Series: Accessories for Air Circuit Breakers
Tariff Code (HS): 853890
Rated Voltage: 400 V AC
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$124.05

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SDA123748R1 is an AUX 6Q auxiliary changeover contact block rated 400 V AC for SACE Emax 2 withdrawable air circuit breakers in the E2.2 to E6.2 frame range. It provides six open-closed changeover contacts for the breaker's withdrawable (W) version, supplied as a loose accessory for configuration on the breaker.

Technical Specifications

SKU 1SDA123748R1
Brand ABB
Series Accessories for Air Circuit Breakers
Catalog Designation AUX 6Q 400Vac E2.2...E6.2 W
EAN 8056221242189
Compatible Breaker Range E2.2 ... E6.2, withdrawable (W)
Rated Voltage 400 V AC
Number of Changeover Contacts 6
Configuration Type Loose
Net Weight 0.2 kg

Selection Notes

This AUX 6Q block provides six open-closed changeover contacts for the withdrawable (W) version of an E2.2 to E6.2 Emax 2 breaker, rated for 400 V AC signalling circuits. Specify it when the installation needs six independent breaker-position signals rather than the lower contact counts offered by the AUP range accessories.

Technical Details

Short Description
ABB AUX 6Q changeover contact block, 400V AC, for Emax 2 E2.2-E6.2 withdrawable breakers.
Rated Voltage (VAC)
400 V AC
Mounting Type
Loose
Catalog No
AUX 6Q 400Vac E2.2...E6.2 W
Delivery Date (Days)
30 days
Model Number
AUX 6Q 400Vac E2.2...E6.2 W
Tariff Code
853890
