ABB 1SDA112891R1 Rating Plug RC R4000 E4.2..E6.2 (Black) Air Circuit Breaker Accessory

% $-41.02
ABB 1SDA112891R1 Rating Plug RC R4000 E4.2..E6.2 Emax 2 ACB Accessory
ABB 1SDA112891R1 Rating Plug RC R4000 E4.2..E6.2 Emax 2 ACB Accessory

ABB 1SDA112891R1 Rating Plug RC R4000 E4.2..E6.2 (Black) Air Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA112891R1
Catalog No: Rating Plug RC R4000 E4.2..E6.2 (Black)
Series: Accessories for Emax 2
Tariff Code (HS): 853890
Breaking Type: Rating Plug R4000
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$41.02

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SDA112891R1 Rating Plug RC R4000 E4.2..E6.2 (Black) sets the rated current (In) of the Ekip electronic release on Emax 2 frames E4.2 to E6.2 at 4000 A. It is a loose, configurable accessory that mounts into the trip unit rather than a complete breaker. Net weight is 0.1 kg.

Technical Specifications

SKU 1SDA112891R1
Brand ABB
Series Accessories for Emax 2
Catalog designation Rating Plug RC R4000 E4.2..E6.2 (Black)
EAN 8056221000512
Net Weight 0.1 kg
Configuration Type Loose or configurable

Selection Notes

The R4000 plug fixes the Ekip release In at 4000 A; pick a lower-coded plug (e.g. R3200) instead when the feeder it protects is rated well below that value, since the plug sets the pickup, not the breaker frame. Order the matching plug for the installed frame size (E4.2 through E6.2) rather than assuming interchangeability across unrelated Emax 2 frames. Keep the plug colour code (Black) on the purchase order, since ABB uses colour to distinguish current ratings at a glance during panel maintenance.

Technical Details

Short Description
ABB 1SDA112891R1 Rating Plug RC R4000, E4.2..E6.2 Emax 2 accessory (Black), EAN 8056221000512.
Mounting Type
Loose or configurable
Catalog No
Rating Plug RC R4000 E4.2..E6.2 (Black)
Delivery Date (Days)
30 days
Model Number
Rating Plug RC R4000 E4.2..E6.2 (Black)
Tariff Code
853890
