ABB 1SDA112889R1 Rating Plug RC R3200 E4.2..E6.2 (Black) Air Circuit Breaker Accessory

% $-41.02
ABB 1SDA112889R1 Rating Plug RC R3200 E4.2-E6.2 Air Circuit Breaker Accessory
ABB 1SDA112889R1 Rating Plug RC R3200 E4.2-E6.2 Air Circuit Breaker Accessory

ABB 1SDA112889R1 Rating Plug RC R3200 E4.2..E6.2 (Black) Air Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA112889R1
Catalog No: Rating Plug RC R3200 E4.2..E6.2 (Black)
Series: Accessories for Emax 2
Tariff Code (HS): 853890
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$41.02

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SDA112889R1 Rating Plug RC R3200 sets a SACE Emax 2 breaker's electronic trip unit to the RC-designated 3200 A configuration and is restricted to the E4.2 and E6.2 frames. It is the highest-current member of the RC rating-plug line offered in this catalog. The accessory weighs 0.1 kg and ships loose, in black.

Technical Specifications

SKU 1SDA112889R1
Brand ABB
Series Accessories for Emax 2
Catalog Designation Rating Plug RC R3200 E4.2..E6.2 (Black)
EAN 8056221000499
Compatible Breaker Frames E4.2, E6.2 (SACE Emax 2)
Current Rating Setting RC R3200 (3200 A)
Color Black
Configuration Type Loose or configurable
Net Weight 0.1 kg

Selection Notes

Like the standard 3200 A plug, this RC variant will not install in an E1.2 or E2.2 breaker -- verify the frame before ordering. Choose it specifically when the project requires the RC configuration; otherwise the standard 3200 A plug covers the same current value for E4.2/E6.2 breakers.

Technical Details

Short Description
RC R3200 rating plug for ABB SACE Emax 2 air circuit breakers, frames E4.2-E6.2.
Catalog No
Rating Plug RC R3200 E4.2..E6.2 (Black)
Delivery Date (Days)
30 days
Model Number
Rating Plug RC R3200 E4.2..E6.2 (Black)
Tariff Code
853890
