ABB 1SDA112888R1 Rating Plug RC R2000 E2.2..E6.2 (Black) Air Circuit Breaker Accessory

% $-41.02
ABB 1SDA112888R1 Rating Plug RC R2000 E2.2-E6.2 Air Circuit Breaker Accessory
ABB 1SDA112888R1 Rating Plug RC R2000 E2.2-E6.2 Air Circuit Breaker Accessory

ABB 1SDA112888R1 Rating Plug RC R2000 E2.2..E6.2 (Black) Air Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA112888R1
Catalog No: Rating Plug RC R2000 E2.2..E6.2 (Black)
Series: Accessories for Emax 2
Tariff Code (HS): 853890
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$41.02

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SDA112888R1 Rating Plug RC R2000 configures a SACE Emax 2 breaker's electronic trip unit to the RC-designated 2000 A setting, valid on the E2.2, E4.2 and E6.2 frames. It is the mid-current member of the RC rating-plug line, distinct from the standard plug offered at the same value. The module weighs 0.1 kg and is supplied loose, in black.

Technical Specifications

SKU 1SDA112888R1
Brand ABB
Series Accessories for Emax 2
Catalog Designation Rating Plug RC R2000 E2.2..E6.2 (Black)
EAN 8056221000482
Compatible Breaker Frames E2.2, E4.2, E6.2 (SACE Emax 2)
Current Rating Setting RC R2000 (2000 A)
Color Black
Configuration Type Loose or configurable
Net Weight 0.1 kg

Selection Notes

This plug does not fit an E1.2 frame, matching the frame restriction of the standard 2000 A plug elsewhere in the range. Confirm the project specification calls for the RC configuration rather than the standard current setting before ordering, since the two lines are not interchangeable despite the shared current value.

Technical Details

Short Description
RC R2000 rating plug for ABB SACE Emax 2 air circuit breakers, frames E2.2-E6.2.
Catalog No
Rating Plug RC R2000 E2.2..E6.2 (Black)
Delivery Date (Days)
30 days
Model Number
Rating Plug RC R2000 E2.2..E6.2 (Black)
Tariff Code
853890
