ABB 1SDA112875R1 Rating Plug 4000 L OFF E4.2..E6.2 (Black) Air Circuit Breaker Accessory

% $-32.79
ABB 1SDA112875R1 Rating Plug 4000 E4.2-E6.2 Air Circuit Breaker Accessory
ABB 1SDA112875R1 Rating Plug 4000 E4.2-E6.2 Air Circuit Breaker Accessory

ABB 1SDA112875R1 Rating Plug 4000 L OFF E4.2..E6.2 (Black) Air Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA112875R1
Catalog No: Rating Plug 4000 L OFF E4.2..E6.2 (Black)
Series: Accessories for Emax 2
Tariff Code (HS): 853890
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$32.79

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

Fitting the ABB 1SDA112875R1 Rating Plug 4000 L OFF E4.2..E6.2 sets a SACE Emax 2 breaker's electronic trip unit to 4000 A, a rating available only on the E4.2 and E6.2 frames. It sits one step below the 5000 A rating in the large-frame portion of the lineup. The module weighs 0.1 kg and is supplied loose, in black.

Technical Specifications

SKU 1SDA112875R1
Brand ABB
Series Accessories for Emax 2
Catalog Designation Rating Plug 4000 L OFF E4.2..E6.2 (Black)
EAN 8056221000352
Compatible Breaker Frames E4.2, E6.2 (SACE Emax 2)
Current Rating Setting 4000 A
Color Black
Configuration Type Loose or configurable
Net Weight 0.1 kg

Selection Notes

4000 A sits between the 3200 A and 5000 A steps and, like them, is only valid on the E4.2 or E6.2 frame -- it cannot be installed in an E1.2 or E2.2 breaker. Select this rating when the feeder's continuous current is closer to 4000 A than to 3200 A, keeping in mind the 5000 A step above it is limited to the E6.2 frame alone.

Technical Details

Short Description
4000 A rating plug for ABB SACE Emax 2 air circuit breakers, frames E4.2-E6.2.
Catalog No
Rating Plug 4000 L OFF E4.2..E6.2 (Black)
Delivery Date (Days)
30 days
Model Number
Rating Plug 4000 L OFF E4.2..E6.2 (Black)
Tariff Code
853890
