ABB 1SDA112872R1 Rating Plug 2500 L OFF E2.2..E6.2 (Black) Air Circuit Breaker Accessory

% $-32.79
ABB 1SDA112872R1 Rating Plug 2500 E2.2-E6.2 Air Circuit Breaker Accessory
ABB 1SDA112872R1 Rating Plug 2500 E2.2-E6.2 Air Circuit Breaker Accessory

ABB 1SDA112872R1 Rating Plug 2500 L OFF E2.2..E6.2 (Black) Air Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA112872R1
Catalog No: Rating Plug 2500 L OFF E2.2..E6.2 (Black)
Series: Accessories for Emax 2
Tariff Code (HS): 853890
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$32.79

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

Installing the ABB 1SDA112872R1 Rating Plug 2500 L OFF E2.2..E6.2 raises a SACE Emax 2 breaker's trip-unit setting to 2500 A, available only on the E2.2, E4.2 and E6.2 frames. It is a step above the 2000 A rating within the same mid-to-high current band. The accessory is supplied loose, weighs 0.1 kg, and is finished in black.

Technical Specifications

SKU 1SDA112872R1
Brand ABB
Series Accessories for Emax 2
Catalog Designation Rating Plug 2500 L OFF E2.2..E6.2 (Black)
EAN 8056221000321
Compatible Breaker Frames E2.2, E4.2, E6.2 (SACE Emax 2)
Current Rating Setting 2500 A
Color Black
Configuration Type Loose or configurable
Net Weight 0.1 kg

Selection Notes

2500 A is the upper current limit for the E2.2-and-above frame band before the lineup restricts further to E4.2 and E6.2 only; pick it over the 2000 A plug when the feeder current leaves little margin at 2000 A, and confirm the breaker is not an E1.2 frame, which cannot accept either rating.

Technical Details

Short Description
2500 A rating plug for ABB SACE Emax 2 air circuit breakers, frames E2.2-E6.2.
Catalog No
Rating Plug 2500 L OFF E2.2..E6.2 (Black)
Delivery Date (Days)
30 days
Model Number
Rating Plug 2500 L OFF E2.2..E6.2 (Black)
Tariff Code
853890
