ABB 1SDA112870R1 Rating Plug 1600 L OFF E1.2..E6.2 (Black) Air Circuit Breaker Accessory

% $-32.79
ABB 1SDA112870R1 Rating Plug 1600 E1.2-E6.2 Air Circuit Breaker Accessory
ABB 1SDA112870R1 Rating Plug 1600 E1.2-E6.2 Air Circuit Breaker Accessory

ABB 1SDA112870R1 Rating Plug 1600 L OFF E1.2..E6.2 (Black) Air Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA112870R1
Catalog No: Rating Plug 1600 L OFF E1.2..E6.2 (Black)
Series: Accessories for Emax 2
Tariff Code (HS): 853890
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$32.79

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SDA112870R1 Rating Plug 1600 L OFF E1.2..E6.2 is the highest current step that still fits every SACE Emax 2 frame from E1.2 to E6.2, setting the electronic trip unit to 1600 A. Current steps above this rating are limited to the larger frames only. It weighs 0.1 kg and is supplied loose, in black.

Technical Specifications

SKU 1SDA112870R1
Brand ABB
Series Accessories for Emax 2
Catalog Designation Rating Plug 1600 L OFF E1.2..E6.2 (Black)
EAN 8056221000307
Compatible Breaker Frames E1.2-E6.2 (full SACE Emax 2 range)
Current Rating Setting 1600 A
Color Black
Configuration Type Loose or configurable
Net Weight 0.1 kg

Selection Notes

1600 A is the last plug in this catalog that works on every frame, including the smaller E1.2 and E2.2 breakers; the next current step up (2000 A) is restricted to the larger E2.2-and-above frames, so confirm the installed breaker's frame size before stepping up. Pick 1600 A over the 1250 A plug when the protected feeder's continuous current leaves little headroom at 1250 A.

Technical Details

Short Description
1600 A rating plug for ABB SACE Emax 2 air circuit breakers, frames E1.2-E6.2.
Catalog No
Rating Plug 1600 L OFF E1.2..E6.2 (Black)
Delivery Date (Days)
30 days
Model Number
Rating Plug 1600 L OFF E1.2..E6.2 (Black)
Tariff Code
853890
