ABB 1SDA112866R1 Rating Plug 800 L OFF E1.2..E6.2 (Black) Air Circuit Breaker Accessory

% $-32.79
ABB 1SDA112866R1 Rating Plug 800 E1.2-E6.2 Air Circuit Breaker Accessory
ABB 1SDA112866R1 Rating Plug 800 E1.2-E6.2 Air Circuit Breaker Accessory

ABB 1SDA112866R1 Rating Plug 800 L OFF E1.2..E6.2 (Black) Air Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA112866R1
Catalog No: Rating Plug 800 L OFF E1.2..E6.2 (Black)
Series: Accessories for Emax 2
Tariff Code (HS): 853890
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$32.79

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

Fitting the ABB 1SDA112866R1 Rating Plug 800 L OFF E1.2..E6.2 into a SACE Emax 2 breaker's electronic trip unit sets the current rating to 800 A, and the plug is compatible with every frame between E1.2 and E6.2. Swapping this plug lets a panel builder change the breaker's current setting without replacing the breaker body. The module weighs 0.1 kg and is supplied loose, in black.

Technical Specifications

SKU 1SDA112866R1
Brand ABB
Series Accessories for Emax 2
Catalog Designation Rating Plug 800 L OFF E1.2..E6.2 (Black)
EAN 8056221000260
Compatible Breaker Frames E1.2-E6.2 (full SACE Emax 2 range)
Current Rating Setting 800 A
Color Black
Configuration Type Loose or configurable
Net Weight 0.1 kg

Selection Notes

The 800 A step is the natural upgrade path from the 630 A plug when a feeder's load grows closer to 800 A, and it should be chosen over the 1000 A plug when the extra headroom is not needed and a tighter long-time pickup is preferred. Full-range plugs from 400 A through 1600 A are interchangeable across the same breaker body, so re-rating a panel later does not require a new breaker frame.

Technical Details

Short Description
800 A rating plug for ABB SACE Emax 2 air circuit breakers, frames E1.2-E6.2.
Catalog No
Rating Plug 800 L OFF E1.2..E6.2 (Black)
Delivery Date (Days)
30 days
Model Number
Rating Plug 800 L OFF E1.2..E6.2 (Black)
Tariff Code
853890
