ABB 1SDA112865R1 Rating Plug 630 L OFF E1.2..E6.2 (Black) Air Circuit Breaker Accessory

% $-32.79
ABB 1SDA112865R1 Rating Plug 630 E1.2-E6.2 Air Circuit Breaker Accessory
ABB 1SDA112865R1 Rating Plug 630 E1.2-E6.2 Air Circuit Breaker Accessory

ABB 1SDA112865R1 Rating Plug 630 L OFF E1.2..E6.2 (Black) Air Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA112865R1
Catalog No: Rating Plug 630 L OFF E1.2..E6.2 (Black)
Series: Accessories for Emax 2
Tariff Code (HS): 853890
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$32.79

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SDA112865R1 Rating Plug 630 L OFF E1.2..E6.2 sets the current rating of the electronic trip unit to 630 A on SACE Emax 2 air circuit breakers across the E1.2 through E6.2 frame range. This plug-in module lets a panel builder adjust breaker In without swapping the circuit breaker itself. It weighs 0.1 kg and ships as a loose, configurable accessory.

Technical Specifications

SKU 1SDA112865R1
Brand ABB
Series Accessories for Emax 2
Catalog Designation Rating Plug 630 L OFF E1.2..E6.2 (Black)
EAN 8056221000253
Compatible Breaker Frames E1.2-E6.2 (full SACE Emax 2 range)
Current Rating Setting 630 A
Color Black
Configuration Type Loose or configurable
Net Weight 0.1 kg

Selection Notes

630 A sits mid-range in the full E1.2..E6.2 plug family -- pick it over the 400 A step when the feeder's continuous current exceeds roughly 400 A, and over the 800 A step when there is no need for the extra headroom. Since this plug fits every Emax 2 frame, selection depends only on the desired trip-unit current, not on which physical breaker size is installed.

Technical Details

Short Description
630 A rating plug for ABB SACE Emax 2 air circuit breakers, frames E1.2-E6.2.
Catalog No
Rating Plug 630 L OFF E1.2..E6.2 (Black)
Delivery Date (Days)
30 days
Model Number
Rating Plug 630 L OFF E1.2..E6.2 (Black)
Tariff Code
853890
