ABB 1SDA112862R1 Rating Plug 250 L OFF E1.2..E2.2 (Black) Air Circuit Breaker Accessory

% $-32.79
ABB 1SDA112862R1 Rating Plug 250 E1.2-E2.2 Air Circuit Breaker Accessory
ABB 1SDA112862R1 Rating Plug 250 E1.2-E2.2 Air Circuit Breaker Accessory

ABB 1SDA112862R1 Rating Plug 250 L OFF E1.2..E2.2 (Black) Air Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA112862R1
Catalog No: Rating Plug 250 L OFF E1.2..E2.2 (Black)
Series: Accessories for Emax 2
Tariff Code (HS): 853890
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$32.79

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

ABB's 1SDA112862R1 Rating Plug 250 L OFF E1.2..E2.2 is the highest current setting available for the E1.2 and E2.2 frames of the SACE Emax 2 air circuit breaker line, configuring the electronic trip unit to 250 A. It installs as a plug-in module, so the breaker's rated current can be changed without replacing the breaker body. Net weight is 0.1 kg; the plug ships black and loose.

Technical Specifications

SKU 1SDA112862R1
Brand ABB
Series Accessories for Emax 2
Catalog Designation Rating Plug 250 L OFF E1.2..E2.2 (Black)
EAN 8056221000222
Compatible Breaker Frames E1.2, E2.2 (SACE Emax 2)
Current Rating Setting 250 A
Color Black
Configuration Type Loose or configurable
Net Weight 0.1 kg

Selection Notes

250 A is the ceiling for the E1.2/E2.2 frame band in this lineup -- specify the next plug up (400 A) only if the breaker is actually built on an E1.2..E6.2-rated frame, since the 100/200/250 A plugs are not valid for larger frames. Choose this step when the protected circuit's continuous current is at or just under 250 A to keep headroom in the long-time overload setting.

Technical Details

Short Description
250 A rating plug for ABB SACE Emax 2 air circuit breakers, frames E1.2-E2.2.
Catalog No
Rating Plug 250 L OFF E1.2..E2.2 (Black)
Delivery Date (Days)
30 days
Model Number
Rating Plug 250 L OFF E1.2..E2.2 (Black)
Tariff Code
853890
