ABB 1SDA112860R1 Rating Plug 100 L OFF E1.2..E2.2 (Black) Air Circuit Breaker Accessory

% $-32.79
ABB 1SDA112860R1 Rating Plug 100 E1.2-E2.2 Air Circuit Breaker Accessory
ABB 1SDA112860R1 Rating Plug 100 E1.2-E2.2 Air Circuit Breaker Accessory

ABB 1SDA112860R1 Rating Plug 100 L OFF E1.2..E2.2 (Black) Air Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA112860R1
Catalog No: Rating Plug 100 L OFF E1.2..E2.2 (Black)
Series: Accessories for Emax 2
Tariff Code (HS): 853890
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$32.79

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SDA112860R1 Rating Plug 100 L OFF E1.2..E2.2 sets the current rating of the electronic trip unit to 100 A on SACE Emax 2 air circuit breakers built on the E1.2 and E2.2 frames. This plug-in accessory lets a panel builder calibrate breaker In without changing the breaker body. It is supplied loose, weighs 0.1 kg, and ships in black.

Technical Specifications

SKU 1SDA112860R1
Brand ABB
Series Accessories for Emax 2
Catalog Designation Rating Plug 100 L OFF E1.2..E2.2 (Black)
EAN 8056221000208
Compatible Breaker Frames E1.2, E2.2 (SACE Emax 2)
Current Rating Setting 100 A
Color Black
Configuration Type Loose or configurable
Net Weight 0.1 kg

Selection Notes

Pick the 100 A plug when the protected feeder's continuous load falls at the low end of the E1.2/E2.2 frame range -- it is the lowest current setting in the Emax 2 rating-plug lineup. Because the plug only fits the E1.2 and E2.2 frames, it is not interchangeable with the larger E4.2/E6.2 accessories; match the plug to the frame size specified on the breaker's nameplate before ordering. Choose a higher-rated plug (200 A or 250 A) from the same E1.2..E2.2 band if the measured load current is closer to those steps.

Technical Details

Short Description
100 A rating plug for ABB SACE Emax 2 air circuit breakers, frames E1.2-E2.2.
Catalog No
Rating Plug 100 L OFF E1.2..E2.2 (Black)
Delivery Date (Days)
30 days
Model Number
Rating Plug 100 L OFF E1.2..E2.2 (Black)
Tariff Code
853890
