ABB 1SDA107474R1 KIT EF XT6 4pcs 1000A 4-Pole Circuit Breaker Accessory

% $-241.28
ABB 1SDA107474R1 KIT EF XT6 extended front terminal kit, 4pcs 1000A
ABB 1SDA107474R1 KIT EF XT6 extended front terminal kit, 4pcs 1000A

ABB 1SDA107474R1 KIT EF XT6 4pcs 1000A 4-Pole Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA107474R1
Catalog No: KIT EF XT6 4pcs 1000A
Series: Accessories for Tmax XT
Tariff Code (HS): 853890
Poles: 4P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$241.28

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SDA107474R1 is a KIT EF XT6 4pcs 1000A extended front terminal accessory for four-pole Tmax XT6 moulded case circuit breakers rated at 1000 A. The four-piece kit adds front terminal extensions across all poles for easier busbar or cable-lug landing. It is supplied loose or configurable, one piece per order.

Technical Specifications

SKU 1SDA107474R1
Brand ABB
Series Accessories for Tmax XT
Catalog Designation KIT EF XT6 4pcs 1000A
Compatible Breaker Tmax XT6, 1000 A, Fixed
Number of Poles 4P
Terminal Connection Type Front Extended
Configuration Type Loose or configurable
Order Multiple 1 piece
Net Weight 2 kg
EAN 8015644101213

Certifications & Standards

  • IEC 60947-2

Selection Notes

Four terminal extensions cover every pole of a four-pole XT6 breaker, keeping busbar spacing consistent across all phases and neutral. The kit targets fixed-mount breakers where terminal depth, not withdrawability, is the limiting factor. Use the three-piece kit instead for a three-pole XT6 installation.

Technical Details

Short Description
ABB KIT EF XT6 4pcs 1000A extended front terminal kit for 4-pole Tmax XT6 breakers.
Mounting Type
Fixed
Catalog No
KIT EF XT6 4pcs 1000A
Number of Poles
4P
Standards
IEC60947-2
Delivery Date (Days)
30 days
Model Number
KIT EF XT6 4pcs 1000A
Tariff Code
853890
