ABB 1SDA107473R1 KIT EF XT6 3pcs 1000A 3-Pole Circuit Breaker Accessory

% $-181.45
ABB 1SDA107473R1 KIT EF XT6 extended front terminal kit, 3pcs 1000A
ABB 1SDA107473R1 KIT EF XT6 extended front terminal kit, 3pcs 1000A

ABB 1SDA107473R1 KIT EF XT6 3pcs 1000A 3-Pole Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA107473R1
Catalog No: KIT EF XT6 3pcs 1000A
Series: Accessories for Tmax XT
Tariff Code (HS): 853890
Poles: 3P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$181.45

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SDA107473R1 is a KIT EF XT6 3pcs 1000A extended front terminal accessory for Tmax XT6 moulded case circuit breakers rated at 1000 A. The three-piece kit extends the breaker's front terminals for easier busbar connection on three-pole fixed installations. It is supplied loose or configurable in single-piece order quantities.

Technical Specifications

SKU 1SDA107473R1
Brand ABB
Series Accessories for Tmax XT
Catalog Designation KIT EF XT6 3pcs 1000A
Compatible Breaker Tmax XT6, 1000 A, Fixed
Number of Poles 3P
Terminal Connection Type Front Extended
Configuration Type Loose or configurable
Order Multiple 1 piece
Net Weight 1.5 kg
EAN 8015644101206

Certifications & Standards

  • IEC 60947-2

Selection Notes

The 3pcs kit extends front terminals on a three-pole XT6 1000 A breaker, giving clearance to land large busbars or cable lugs without crowding the fixed breaker's standard terminal shroud. It suits panel layouts where the incoming or outgoing conductors need extra terminal depth rather than a withdrawable breaker configuration. Choose the matching four-pole kit instead when the installation is a four-pole XT6 breaker.

Technical Details

Short Description
ABB KIT EF XT6 3pcs 1000A extended front terminal kit for 3-pole Tmax XT6 breakers.
Mounting Type
Fixed
Catalog No
KIT EF XT6 3pcs 1000A
Number of Poles
3P
Standards
IEC60947-2
Delivery Date (Days)
30 days
Model Number
KIT EF XT6 3pcs 1000A
Tariff Code
853890
