ABB 1SDA105003R1 PB 100mm 6pcs XT5 4p KIT PA.DI.PH.HI Phase Divider Circuit Breaker Accessory

% $-12.88
ABB 1SDA105003R1 PB 100mm phase divider partition kit for Tmax XT5, 6pcs 4p
ABB 1SDA105003R1 PB 100mm phase divider partition kit for Tmax XT5, 6pcs 4p

ABB 1SDA105003R1 PB 100mm 6pcs XT5 4p KIT PA.DI.PH.HI Phase Divider Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA105003R1
Catalog No: PB 100mm 6pcs XT5 4p KIT PA.DI.PH.HI
Series: Accessories for Tmax XT
Tariff Code (HS): 853890
Poles: 4P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$12.88

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SDA105003R1 is a PB 100mm 6pcs XT5 4p phase-divider partition kit for four-pole Tmax XT5 breakers, with a 100 mm partition height. The six-piece kit covers all phase and neutral gaps on a four-pole breaker to reduce the risk of phase-to-phase arc propagation. It ships loose or configurable, one piece per order.

Technical Specifications

SKU 1SDA105003R1
Brand ABB
Series Accessories for Tmax XT
Catalog Designation PB 100mm 6pcs XT5 4p KIT PA.DI.PH.HI
Compatible Breaker Tmax XT5
Number of Poles 4P
Partition Height 100 mm
Configuration Type Loose or configurable
Order Multiple 1 piece
Net Weight 0.167 kg
EAN 8015644070953

Certifications & Standards

  • IEC 60947-2

Selection Notes

Six partitions cover every gap across a four-pole breaker's three phases and neutral, one more divider than the three-pole four-piece kit needs. The 100 mm height matches the XT5 and XT6 three-pole kits, keeping partition height consistent across a mixed-pole switchboard. Choose the four-piece kit instead for a three-pole XT5 breaker.

Technical Details

Short Description
ABB PB 100mm 6pcs XT5 4p phase divider partition kit for 4-pole Tmax XT5 breakers.
Catalog No
PB 100mm 6pcs XT5 4p KIT PA.DI.PH.HI
Number of Poles
4P
Standards
IEC60947-2
Delivery Date (Days)
30 days
Model Number
PB 100mm 6pcs XT5 4p KIT PA.DI.PH.HI
Tariff Code
853890
