ABB 1SDA104798R1 AUX-C 3Q+1SY 250V AC XT5-XT6 W 4 CO Contacts Circuit Breaker Accessory

% $-80.88
ABB 1SDA104798R1 AUX-C 3Q+1SY auxiliary contact for Tmax XT5-XT6 breaker
ABB 1SDA104798R1 AUX-C 3Q+1SY auxiliary contact for Tmax XT5-XT6 breaker

ABB 1SDA104798R1 AUX-C 3Q+1SY 250V AC XT5-XT6 W 4 CO Contacts Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA104798R1
Catalog No: AUX-C 3Q+1SY 250V AC XT5-XT6 W
Series: Accessories for Tmax XT
Tariff Code (HS): 853890
Rated Voltage: 250 V AC
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$80.88

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SDA104798R1 is an AUX-C 3Q+1SY auxiliary contact accessory cabled for withdrawable Tmax XT5 and XT6 circuit breakers. It delivers four AC changeover (SPDT) contacts at 250 V, pairing three breaker-position signals with one tripped-indication contact for panels that need wider status monitoring. The block ships loose or configurable in single-piece quantities.

Technical Specifications

SKU 1SDA104798R1
Brand ABB
Series Accessories for Tmax XT
Catalog Designation AUX-C 3Q+1SY 250V AC XT5-XT6 W
Compatible Breakers Tmax XT5, XT6 (Withdrawable)
Number of Auxiliary Contacts CO (SPDT) 4
Current Type AC
Rated Voltage 250 V
Configuration Type Loose or configurable
Order Multiple 1 piece
Net Weight 0.085 kg
EAN 8056221026963

Certifications & Standards

  • IEC 60947-2
  • UL 489

Selection Notes

Four CO contacts let the 1SDA104798R1 feed three independent position signals plus a trip indication into a single PLC input card, cutting the terminal count versus wiring two smaller blocks. The 250 V AC rating lines up with the control voltage already used across the XT5/XT6 auxiliary contact family, keeping wiring practice consistent on a switchboard. Select a lower-contact-count block instead when the panel only needs trip status or a single position signal.

Technical Details

Short Description
ABB AUX-C 3Q+1SY auxiliary contact block for XT5-XT6 withdrawable breakers, 4 CO contacts, 250 V AC.
Rated Voltage (VAC)
250 V AC
Catalog No
AUX-C 3Q+1SY 250V AC XT5-XT6 W
Standards
IEC60947-2, UL489
Delivery Date (Days)
30 days
Model Number
AUX-C 3Q+1SY 250V AC XT5-XT6 W
Tariff Code
853890
