ABB 1SDA104791R1 AUX-C 1S51 250V AC/dC XT5-XT6 W 1 CO Contact Circuit Breaker Accessory

% $-27.13
ABB 1SDA104791R1 AUX-C 1S51 auxiliary contact for Tmax XT5-XT6 breaker
ABB 1SDA104791R1 AUX-C 1S51 auxiliary contact for Tmax XT5-XT6 breaker

ABB 1SDA104791R1 AUX-C 1S51 250V AC/dC XT5-XT6 W 1 CO Contact Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA104791R1
Catalog No: AUX-C 1S51 250V AC/dC XT5-XT6 W
Series: Accessories for Tmax XT
Tariff Code (HS): 853890
Rated Voltage: 250 V AC/DC
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$27.13

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SDA104791R1 is an AUX-C 1S51 auxiliary contact accessory cabled for withdrawable Tmax XT5 and XT6 moulded case circuit breakers. It provides one changeover (SPDT) contact rated at 250 V AC/DC, used for remote tripped indication. The contact block ships loose or configurable, in single-piece order quantities for panel wiring.

Technical Specifications

SKU 1SDA104791R1
Brand ABB
Series Accessories for Tmax XT
Catalog Designation AUX-C 1S51 250V AC/dC XT5-XT6 W
Compatible Breakers Tmax XT5, XT6 (Withdrawable)
Number of Auxiliary Contacts CO (SPDT) 1
Current Type AC/DC
Rated Voltage 250 V
Configuration Type Loose or configurable
Order Multiple 1 piece
Net Weight 0.085 kg
EAN 8056221026918

Certifications & Standards

  • IEC 60947-2
  • UL 489

Selection Notes

The single CO contact on the 1SDA104791R1 reports breaker trip status to a PLC or annunciator panel without using a second accessory slot. Its 250 V AC/DC rating lets the same contact wire into either an AC control circuit or a DC SCADA input. Choose a multi-contact auxiliary kit instead when the application needs more than one changeover contact alongside the tripped-indication signal.

Technical Details

Short Description
ABB AUX-C 1S51 auxiliary contact block for XT5-XT6 withdrawable breakers, 1 CO contact, 250 V AC/DC.
Rated Voltage (VAC)
250 V AC/DC
Catalog No
AUX-C 1S51 250V AC/dC XT5-XT6 W
Standards
IEC60947-2, UL489
Delivery Date (Days)
30 days
Model Number
AUX-C 1S51 250V AC/dC XT5-XT6 W
Tariff Code
853890
