ABB 1SDA101710R1 XT7H M 800 Ekip Dip LS/I In=800A 4p F F 800A 4-Pole Fixed Power Circuit Breaker

The ABB 1SDA101710R1 — catalog number XT7H M 800 Ekip Dip LS/I In=800A 4p F F — is an 800 A, 4-pole fixed-mount power circuit breaker from the Tmax XT7 series, designed for transformer, generator, and installation protection in demanding industrial environments. Equipped with the Ekip Dip LS/I electronic trip unit, it delivers precise long-time and instantaneous overcurrent protection, making it a reliable solution for main distribution boards and power distribution panels.

Technical Specifications

Certifications & Standards

• CE: Conforms to European Economic Area product safety and regulatory requirements
• IEC 60947-2: Compliant with the international standard for low-voltage circuit breakers
• RoHS: Restriction of Hazardous Substances — compliant with EU Directive 2011/65/EU
• EU Directive 2011/65/EU: Restriction of the use of certain hazardous substances in electrical and electronic equipment
• Amendment 2015/863: Updated RoHS substance list compliance
• REACH: Compliant with EU REACH regulation on chemical substances
• UL 2799: Listed under UL standard for electrical component assemblies
• WEEE: Compliant with Waste Electrical and Electronic Equipment Directive for responsible end-of-life disposal

Applications & Use Cases

• Transformer feeder and secondary protection in LV distribution systems
• Generator protection and disconnection in standby and prime power installations
• Main incomer protection in industrial distribution boards and switchgear panels
• Installation protection in manufacturing plants, data centres, and commercial buildings
• High-demand applications requiring reliable overcurrent protection at 800 A
