ABB 1SDA101654R1 XT7S M 800 Ekip Dip LS/I In=800A 4p F F Moulded Case Circuit Breaker

The ABB 1SDA101654R1 XT7S M 800 Ekip Dip LS/I In=800A 4p F F is a high-performance 4-pole fixed-mount power circuit-breaker from ABB's Tmax XT7S series, rated at 800A with a breaking capacity of 85 kA at 220V AC. Designed for demanding trafo, generator, and installation protection applications, this molded case circuit-breaker features ABB's Ekip Dip LS/I electronic trip unit for precise long-time and instantaneous protection, making it a trusted solution for industrial switchgear panels and critical power distribution infrastructures.

Technical Specifications

Certifications & Standards

• IEC 60947-2: Complies with the international standard for low-voltage switchgear and controlgear — circuit-breakers, ensuring verified safety and performance ratings.
• CE: Meets European Union safety, health, and environmental protection requirements for electrical equipment placed on the EU market.
• RoHS: Compliant with EU Restriction of Hazardous Substances directive, confirming the product is free from restricted hazardous materials.
• REACH: Conforms to EU REACH regulation requirements regarding chemical substances used in manufacturing.
• WEEE: Registered under the Waste Electrical and Electronic Equipment directive for responsible end-of-life disposal and recycling.

Applications & Use Cases

• Transformer and generator feeder protection in industrial power distribution systems
• Main and sub-main incoming circuit protection in large switchgear panels
• Installation protection for heavy industrial machinery and process equipment
• Critical infrastructure power distribution boards requiring high breaking capacity
• Data centers, utilities, and manufacturing facilities requiring reliable 4-pole overcurrent protection
