ABB 1SDA101430R1 XT7H M 800 Ekip Dip LS/I In=800A 3p F F Moulded Case Circuit Breaker

The ABB 1SDA101430R1 XT7H M 800 Ekip Dip LS/I In=800A 3p F F is a high-performance 3-pole fixed power circuit-breaker from the Tmax XT7 series, rated at 800A with a breaking capacity of 100kA at 220V AC. Designed for demanding trafo, generator, and installation protection applications, the XT7H M 800 Ekip Dip LS/I In=800A 3p F F delivers precise overcurrent and short-circuit protection via its Ekip Dip LS/I electronic trip unit, making it a dependable choice for industrial switchboards and control panels.

Technical Specifications

Certifications & Standards

• CE: Compliant with European Community directives for electrical safety and market access
• RoHS: Restriction of Hazardous Substances — compliant with EU Directive 2011/65/EU
• REACH: Registration, Evaluation, Authorisation and Restriction of Chemicals compliance
• EU Directive 2011/65/EU: European RoHS directive for restriction of hazardous substances in electrical and electronic equipment
• Amendment 2015/863: Updated RoHS substance restrictions per EU Amendment 2015/863
• IEC 60947-2: International standard for low-voltage switchgear and controlgear — circuit-breakers
• WEEE: Waste Electrical and Electronic Equipment directive compliance for end-of-life recycling

Applications & Use Cases

• Transformer and generator protection in industrial power distribution systems
• Main and feeder protection in low-voltage switchboards and motor control centres
• Installation protection for large industrial and commercial electrical systems
• Control panel integration requiring high breaking capacity and electronic trip coordination
• Applications demanding precise long-time and instantaneous (LS/I) overcurrent protection
