ABB 1SDA101366R1 XT7S M 800 Ekip Dip LS/I In=800A 3p F F Moulded Case Circuit Breaker

The ABB 1SDA101366R1 XT7S M 800 Ekip Dip LS/I In=800A 3p F F is a fixed-mount, 3-pole power circuit-breaker from the Tmax XT7 series, purpose-built for transformer, generator, and installation protection in demanding industrial environments. Rated at 800 A with a breaking capacity of 85 kA at 220 V AC, the XT7S M 800 Ekip Dip LS/I In=800A 3p F F delivers robust overcurrent protection through its Ekip Dip LS/I electronic trip unit, combining long-time and instantaneous protection functions for precise, reliable fault interruption.

Technical Specifications

Certifications & Standards

• CE: Compliant with EU product safety, health, and environmental protection requirements
• RoHS: Compliant with EU Directive 2011/65/EU on restriction of hazardous substances in electrical equipment
• Amendment 2015/863: Compliant with the updated RoHS substance restrictions under EU Directive 2015/863
• REACH: Compliant with EU Regulation (EC) No 1907/2006 concerning the registration, evaluation, authorisation, and restriction of chemicals
• WEEE: Registered under the Waste Electrical and Electronic Equipment Directive for responsible end-of-life disposal
• IEC 60947-2: Designed and tested in accordance with the international standard for low-voltage switchgear and controlgear — circuit-breakers

Applications & Use Cases

• Transformer feeder and outgoing protection in industrial power distribution boards
• Generator protection in standby and prime power installations
• Installation protection for industrial plants, commercial buildings, and critical infrastructure
• Main incomer and bus-coupler positions in low-voltage switchgear assemblies
• Protection of large motor loads and busbar systems requiring high breaking capacity
