ABB 1SDA100911R1 XT7H 1000 Ekip Touch Meas.LSI 1000 3p FF 70kA Molded Case Circuit Breaker (MCCB)

% $-1,918.15
ABB 1SDA100911R1 Tmax XT7H 1000A 3P MCCB - 70kA Icu, Ekip Touch Meas.LSI
ABB 1SDA100911R1 Tmax XT7H 1000A 3P MCCB - 70kA Icu, Ekip Touch Meas.LSI

ABB 1SDA100911R1 XT7H 1000 Ekip Touch Meas.LSI 1000 3p FF 70kA Molded Case Circuit Breaker (MCCB)

Brand: ABB
Reference No: 1SDA100911R1
Catalog No: XT7H 1000 Ekip Touch Meas.LSI 1000 3p FF
Series: Tmax XT
Tariff Code (HS): 853620
Rated Current: 1000
Breaking Capacity: 70 kA
Breaking Type: Ekip Touch Meas.LSI
Rated Voltage: 690 V AC
Poles: 3P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$1,918.15

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

ABB's Tmax XT7H 1SDA100911R1 is a fixed three-pole moulded case circuit breaker rated 1000 A on the XT7 frame, with front terminals and a lever operating mechanism. Short-circuit performance level H gives it 70 kA Icu at 415 V AC. The Ekip Touch Meas.LSI electronic release adds long-time, short-time and instantaneous protection plus integrated power metering.

Technical Specifications

SKU 1SDA100911R1
Brand ABB
Series / Frame Tmax XT7 (XT7)
Catalog Designation XT7H 1000 Ekip Touch Meas.LSI 1000 3p FF
EAN 8056221009652
Number of Poles 3P
Rated Current (In/Iu) 1000 A
Rated Operational Voltage (Ue) 690 V AC
Rated Insulation Voltage (Ui) 1000 V
Rated Impulse Withstand Voltage (Uimp) 8 kV
Rated Ultimate Breaking Capacity (Icu) 100 kA (220-240 V AC) | 70 kA (380-415 V AC) | 65 kA (440 V AC) | 50 kA (500-525 V AC) | 42 kA (690 V AC)
Rated Service Breaking Capacity (Ics) 100 kA (220-240 V AC) | 70 kA (380-415 V AC) | 65 kA (440 V AC) | 50 kA (500-525 V AC) | 42 kA (690 V AC)
Rated Short-Time Withstand Current (Icw, 1s) 20 kA
Release / Trip Unit Ekip Touch Meas.LSI (Electronic - EL)
Short-Circuit Performance Level H
Operating Mechanism Lever (manual)
Terminal Connection Type Front
Power Loss per Pole 37 W
Ambient Air Temperature (Operation) -40 to 125 °C
Net Width 210 mm
Net Height 268 mm
Net Depth 166 mm
Net Weight 9.7 kg

Certifications & Standards

  • IEC/EN 60947-2

Selection Notes

The Ekip Touch Meas.LSI release decodes as L (long-time overload), S (short-time delay) and I (instantaneous) protection with an integrated metering display, so this breaker can report load and energy data without a separate meter. At performance level H, 70 kA Icu at 415 V AC and a 20 kA Icw make it suitable as a main incomer with time-graded coordination to downstream XT breakers. Choose the 4-pole version instead where the neutral conductor needs switching; step up to the 1250 A or 1600 A variants in the same XT7 frame if the feeder current exceeds 1000 A.

Technical Details

Short Description
ABB Tmax XT7H 1SDA100911R1, 1000A 3-pole fixed MCCB, Ekip Touch Meas.LSI release, 70 kA Icu at 415V AC.
Rated Current (Ampere)
1000
Breaking Capacity (kA)
70 kA
Rated Voltage (VAC)
690 V AC
Mounting Type
Fixed
Catalog No
XT7H 1000 Ekip Touch Meas.LSI 1000 3p FF
Number of Poles
3P
Standards
IEC60947-2
Delivery Date (Days)
30 days
Model Number
XT7H 1000 Ekip Touch Meas.LSI 1000 3p FF
Tariff Code
853620
