ABB 1SDA100892R1 XT7H 1250 Ekip Dip LS/I In=1250A 3p F F Moulded Case Circuit Breaker

The ABB 1SDA100892R1 XT7H 1250 Ekip Dip LS/I In=1250A 3p F F is a 3-pole fixed-mounted power circuit-breaker from the Tmax XT7 series, rated at 1250 A with a breaking capacity of 100 kA at 220 V AC. Designed for demanding trafo, generator, and installation protection applications, this breaker features the Ekip Dip LS/I electronic trip unit for precise long-time and instantaneous protection. Certified to IEC 60947-2 and CE-marked, it is built for reliable performance in industrial power distribution systems.

Technical Specifications

Certifications & Standards

• CE: Conforms to European Union product safety and electromagnetic compatibility requirements
• RoHS: Compliant with EU Directive 2011/65/EU on restriction of hazardous substances in electrical equipment
• REACH: Compliant with EU REACH regulation on chemical substance safety
• EU Directive 2011/65/EU: RoHS2 compliance covering restricted hazardous substances in electrical and electronic equipment
• EU Directive 2015/863: RoHS3 amendment extending the list of restricted substances
• IEC 60947-2: Meets the international standard for low-voltage switchgear and controlgear — circuit-breakers
• WEEE: Compliant with the EU Waste Electrical and Electronic Equipment directive for end-of-life recycling

Applications & Use Cases

• Transformer feeder and secondary-side protection in industrial and commercial power distribution
• Generator circuit protection in standby and prime power installations
• Main and sub-main installation protection in large industrial facilities
• Control panel and switchboard integration requiring compact 3-pole fixed circuit-breaker solutions
• Applications demanding high breaking capacity (100 kA) with electronic LS/I trip coordination
