Part number
1SDA080849R1
Model no
XT1S
$174.54 Low stock Dispatch Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days. · From Türkiye

ABB 1SDA080849R1 XT1S 160 TMD 40-450 4p F F 40A 4-Pole 50kA Fixed Moulded Case Circuit Breaker

Rated current
40 A
Poles
4P
Breaking capacity
(400) 50 kA
EAN
8015644873776
Description

About the XT1S

The ABB XT1S 160 TMD 40-450 4p F F (SKU: 1SDA080849R1) is a 4-pole fixed power circuit-breaker from the Tmax XT1 series, engineered for transformer, generator, and installation protection in industrial power distribution systems. Rated at 40 A with a breaking capacity of 50 kA at 400 V AC, this moulded case circuit-breaker delivers reliable overcurrent and short-circuit protection in demanding environments.

Certifications & Standards

  • RoHS: Compliant with EU Restriction of Hazardous Substances regulations
  • REACH: Compliant with EU REACH chemical safety regulation
  • EU Directive 2011/65/EU: Restriction of hazardous substances in electrical and electronic equipment
  • Amendment 2015/863: Updated RoHS substance list compliance
  • IEC 60947-2: Low-voltage switchgear and controlgear — circuit-breakers standard
  • CE: Conformité Européenne mark — meets EU safety and performance requirements
  • WEEE: Compliant with EU Waste Electrical and Electronic Equipment Directive

Applications & Use Cases

The ABB XT1S 160 TMD 40-450 4p F F is ideally suited for a broad range of industrial and commercial power distribution applications. Its high breaking capacity makes it a preferred choice for protection of transformers and generators, where fault currents can be exceptionally high. The 4-pole fixed configuration integrates seamlessly into control panels, switchboards, and motor control centres, providing overcurrent and short-circuit protection across all active and neutral conductors. Typical deployments include industrial automation systems, building services distribution boards, data centres, and manufacturing facilities where reliable electrical protection is non-negotiable. The Tmax XT1 series is recognised by electrical engineers and procurement professionals for its compact form factor, robust construction, and compliance with international standards including IEC 60947-2.

Specification

Full specification

57 values · Last verified 30 Oct 2026

Material Compliance 1

RoHS Information Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

Dimensions 4

Product Net Width 101.6 mm
Product Net Height 130 mm
Product Net Depth / Length 70 mm
Product Net Weight 1.3 kg

Additional Information 5

Circuit Breaker Type to be Associated Power Distribution
Product Main Type SACE Tmax XT
Product Name Moulded Case Circuit Breaker
Product Type Automatic Circuit Breaker
Version F
Show all 57 specifications ↓ Show less ↑47 more values in Identification, Technical, External Classifications and Standards, Logistics.

Identification 11

Part number 1SDA080849R1
Type designation XT1S
Brand ABB
Condition New, factory sealed
Source ABB and its authorised distributors
Warranty Manufacturer warranty
EAN 8015644873776
ETIM class EC000228
eCl@ss 27370409
Minimum Order Quantity 1 piece
Customs Tariff Number 85362090

Technical 23

Current Type AC/DC
Electrical Durability 120 cycles per hour, 8000 cycle
Mechanical Durability 240 cycles per hour, 25000 cycle
Number of Poles 4P
Opening Time CB with SOR 30 ms, CB with UVR 30 ms
Order Multiple 1 piece
Power Loss 7.8 W
Rated Current (In) 160 A
Rated Impulse Withstand Voltage (Uimp) 8 kV
Rated Instantaneous Short-Circuit Current Setting (Ii) 450 A
Rated Insulation Voltage (Ui) 800 V
Rated Operational Voltage 690 V
Rated Service Short-Circuit Breaking Capacity (Ics) (220 V AC) 80 kA, (230 V AC) 80 kA, (240 V AC) 80 kA, (380 V AC) 50 kA, (415 V AC) 37.5 kA, (440 V AC) 25 kA, (500 V AC) 18 kA, (525 V AC) 17.5 kA, (690 V AC) 5 kA, (250 V DC) 2 Poles in Series 50 kA, (500 V DC) 3 Poles in Series 50 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu) (220 V AC) 85 kA, (230 V AC) 85 kA, (240 V AC) 85 kA, (380 V AC) 50 kA, (415 V AC) 50 kA, (440 V AC) 50 kA, (500 V AC) 36 kA, (525 V AC) 35 kA, (690 V AC) 8 kA, (250 V DC) 2 Poles in Series 50 kA, (500 V DC) 3 Poles in Series 50 kA
Rated Uninterrupted Current (Iu) 160 A
Rated Voltage (Ur) 690 V
Release TMD
Release Type TM
Setting Range 28...40 A
Short-Circuit Performance Level S
Standards IEC60947-2
Sub-type XT1
Terminal Connection Type Front

External Classifications and Standards 3

ETIM 10 EC000228 - Power circuit-breaker for trafo/generator/installation protection
WEEE Category 5. Small Equipment (No External Dimension More Than 50 cm)
eClass V11.1 : 27370409

Logistics 10

Package Level 1 Units box 1 piece
Package Level 1 Width 128 mm
Package Level 1 Height 135 mm
Package Level 1 Depth / Length 143 mm
Package Level 1 Gross Weight 1.4 kg
Package Level 1 EAN 8015644873776
Shipping weight 1.4 kg
Ships from Türkiye
Dispatch 17 Nov
Stock Low stock

Source: manufacturer data · Last verified: 30 Oct 2026
