ABB 1SDA068282R1 XT3S 250 MA200 Im=1200...2400 3p F F 200A 3-Pole Fixed Air Circuit Breaker

The ABB 1SDA068282R1 XT3S 250 MA200 Im=1200...2400 3p F F is a 200A, 3-pole fixed-mount air circuit breaker from the Tmax XT3S series, designed for low-voltage power distribution and motor protection applications. Delivering a breaking capacity of 85 kA at 220 V AC, this ACB provides robust short-circuit protection with an adjustable instantaneous magnetic trip range of 1200–2400 A. Compliant with IEC 60947-2, CE, and ATEX standards, the XT3S 250 MA200 Im=1200...2400 3p F F is engineered for demanding industrial switchgear environments.

Technical Specifications

Certifications & Standards

• RoHS: Compliant with the Restriction of Hazardous Substances Directive
• REACH: Compliant with EU REACH chemical safety regulation
• EU Directive 2011/65/EU: Restriction of hazardous substances in electrical and electronic equipment
• Amendment 2015/863: Updated RoHS substance list compliance
• IEC 60947-2: International standard for low-voltage circuit breakers
• IEC60947-2: Verified dual-reference compliance for low-voltage switchgear
• EN45555: General methods for the assessment of the ability to recover materials and energy from electrical and electronic equipment
• ATEX: Certified for use in potentially explosive atmospheres
• CE: Conformité Européenne marking — meets EU safety, health, and environmental requirements
• VDE: Certified by the Association for Electrical, Electronic & Information Technologies (Germany)

Applications & Use Cases

• Industrial motor protection and control panels requiring precise instantaneous trip settings
• Low-voltage power distribution boards in manufacturing facilities
• Switchgear assemblies demanding high breaking capacity up to 85 kA
• Hazardous area installations where ATEX-certified equipment is mandatory
• OEM panel builders specifying IEC 60947-2 compliant circuit breakers
