ABB 1SDA073768R1 AUP Ekip aux pos.con.E1.2/3.E6.2/3-XT7/M Air Circuit Breaker Accessory

% $-54.43
ABB 1SDA073768R1 AUP Ekip auxiliary position contact for E1.2/3, E6.2/3, XT7, XT7M
ABB 1SDA073768R1 AUP Ekip auxiliary position contact for E1.2/3, E6.2/3, XT7, XT7M

ABB 1SDA073768R1 AUP Ekip aux pos.con.E1.2/3.E6.2/3-XT7/M Air Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA073768R1
Catalog No: AUP Ekip aux pos.con.E1.2/3.E6.2/3-XT7/M
Series: Accessories for Emax 2
Tariff Code (HS): 853890
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$54.43

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SDA073768R1 is an AUP Ekip auxiliary position contact for Emax 2 E1.2/3 and E6.2/3 breakers fitted with the electronic Ekip release, also compatible with Tmax XT7 and XT7M. It supplies a single SPDT (CO) contact that reports breaker open/closed status, supplied loose for configuration on the breaker, one piece per order.

Technical Specifications

SKU 1SDA073768R1
Brand ABB
Series Accessories for Emax 2
Catalog Designation AUP Ekip aux pos.con.E1.2/3.E6.2/3-XT7/M
EAN 8015644777012
Compatible Breaker Range E1.2/3, E6.2/3, XT7, XT7M
Number of Auxiliary Contacts CO (SPDT) 1
Configuration Type Loose or configurable
Order Multiple 1 piece
Product Net Width 135 mm
Product Net Height 55 mm
Product Net Depth 145 mm
Net Weight 0.03 kg

Certifications & Standards

    Selection Notes

    This single-contact Ekip position block is the smallest in the AUP range covered here, suited to installations needing just one additional open/closed signal from an Emax 2 or Tmax XT7 breaker's Ekip release. Order a multi-contact AUP block instead when a monitoring or PLC system needs several independent status points from the same breaker.

    Technical Details

    Short Description
    ABB AUP Ekip auxiliary position contact, 1 SPDT contact, for E1.2/3, E6.2/3, XT7, XT7M breakers.
    Mounting Type
    Loose / Configurable
    Catalog No
    AUP Ekip aux pos.con.E1.2/3.E6.2/3-XT7/M
    Standards
    IEC/UL
    Delivery Date (Days)
    30 days
    Model Number
    AUP Ekip aux pos.con.E1.2/3.E6.2/3-XT7/M
    Tariff Code
    853890
