ABB 1SDA072782R1 E1.2N 1000 Ekip Dip LSI 4p WMP 66kA Air Circuit Breaker

% $-3,806.68
ABB 1SDA072782R1 E1.2N 1000 Ekip Dip LSI 4p WMP Air Circuit Breaker - 66 kA
ABB 1SDA072782R1 E1.2N 1000 Ekip Dip LSI 4p WMP Air Circuit Breaker - 66 kA

ABB 1SDA072782R1 E1.2N 1000 Ekip Dip LSI 4p WMP 66kA Air Circuit Breaker

Brand: ABB
Reference No: 1SDA072782R1
Catalog No: E1.2N 1000 Ekip Dip LSI 4p WMP
Series: Emax 2
Tariff Code (HS): 853620
Rated Current: 1000
Breaking Capacity: 66 kA
Breaking Type: Ekip Dip LSI
Rated Voltage: 690 V AC
Poles: 4P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$3,806.68

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

Order code 1SDA072782R1 is the ABB SACE Emax 2 E1.2N 1000 Ekip Dip LSI 4p WMP, a four-pole withdrawable moving part rated 1000 A (Iu) with a 66 kA ultimate breaking capacity (Icu) at 400 V AC. It supplies the drawout truck only — a compatible fixed part and cradle must already be in place for the breaker to operate.

Technical Specifications

SKU 1SDA072782R1
Brand ABB
Series SACE Emax 2
Catalog Designation E1.2N 1000 Ekip Dip LSI 4p WMP
EAN 8015644766320
Number of Poles 4P
Neutral Pole Current 100% of Iu
Rated Current (In / Iu) 1000 A
Rated Operational Voltage (Ue) 690 V AC
Rated Insulation Voltage (Ui) 1000 V AC
Rated Impulse Withstand Voltage (Uimp) 12 kV (IEC 60947-2)
Rated Ultimate Breaking Capacity (Icu) at 400 V AC 66 kA
Rated Service Breaking Capacity (Ics) at 400 V AC 50 kA (100% of Icu)
Rated Short-Time Withstand Current (Icw) 50 kA / 1 s, 30 kA / 3 s
Release / Trip Unit Ekip Dip LSI
Short-Circuit Performance Level N
Connecting Capacity 1000 mm²
Mounting Withdrawable (moving part only — fixed part/cradle ordered separately)
Current Type AC
Suitable for IT Networks Yes, up to 690 V
Power Loss 156 W
Net Dimensions (W x H x D) 348 x 363.5 x 271 mm
Net Weight 20 kg

Selection Notes

The short-time delay (S) stage in Ekip Dip LSI, combined with a 50 kA/1 s Icw, is what makes this 1000 A moving part suitable for a main incomer position with selective coordination downstream, unlike the LI-only moving parts in the same E1.2N frame that trip instantaneously. Choosing the withdrawable WMP version over the fixed F F equivalent trades a bolted connection for drawout isolation, letting the truck be racked out for maintenance without disconnecting the busbar.

Technical Details

Short Description
ABB SACE Emax 2 E1.2N 1000 Ekip Dip LSI 4p WMP moving part, 1000 A, 66 kA Icu at 400 V AC, withdrawable.
Rated Current (Ampere)
1000
Breaking Capacity (kA)
66 kA
Rated Voltage (VAC)
690 V AC
Mounting Type
Withdrawable
Catalog No
E1.2N 1000 Ekip Dip LSI 4p WMP
Number of Poles
4P
Delivery Date (Days)
30 days
Model Number
E1.2N 1000 Ekip Dip LSI 4p WMP
Tariff Code
853620
