ABB 1SDA071431R1 E1.2N 1000 Ekip Dip LI 4p F F 1000A 4P 66kA Air Circuit Breaker

The ABB 1SDA071431R1 E1.2N 1000 Ekip Dip LI 4p F F is a 4-pole, 1000A fixed-mount air circuit breaker from the SACE Emax2 E1.2 series, delivering a breaking capacity of 66 kA at 400 V AC. Equipped with the Ekip Dip LI electronic trip unit, this low voltage ACB provides precise overload (L) and short-circuit (I) protection for demanding power distribution and switchgear applications. Compact at 280 mm × 296 mm × 183 mm and weighing 16 kg, the E1.2N 1000 Ekip Dip LI 4p F F is engineered for reliability in industrial and commercial installations.

Technical Specifications

Certifications & Standards

• CE: Compliant with applicable European Union directives for electrical equipment
• RoHS: Compliant with EU Directive 2011/65/EU — restriction of hazardous substances in electrical equipment
• REACH: Compliant with EU REACH regulation on chemical substances
• EU Directive 2011/65/EU & Amendment 2015/863 (July 22, 2019): Fully compliant with RoHS recast and its amendment regarding restricted substances
• IEC: Designed and tested in accordance with International Electrotechnical Commission standards
• IEC 60947: Compliant with IEC 60947 — Low-voltage switchgear and controlgear
• UL 2799: Certified to UL 2799 standard for electrical systems
• ATEX: Assessed for use in potentially explosive atmospheres per ATEX directive
• CSA: Certified to Canadian Standards Association requirements
• VDE: Tested and approved to VDE (Verband der Elektrotechnik) standards
• WEEE: Registered under the Waste Electrical and Electronic Equipment directive for responsible end-of-life disposal

Applications & Use Cases

The ABB E1.2N 1000 Ekip Dip LI 4p F F air circuit breaker is widely specified for main incoming and bus-coupler positions in low-voltage main distribution boards (MDB), power distribution centers (PDC), and motor control centers (MCC). Its 1000 A rated current and 66 kA breaking capacity at 400 V AC make it suitable for protecting downstream feeders, large motors, transformers, and generators in industrial plants, data centers, infrastructure projects, and commercial buildings. The four-pole fixed configuration supports both three-phase plus neutral (3P+N) installations, ensuring comprehensive circuit protection across all live and neutral conductors.
