ABB 1SDA068362R1 XT4H 250 TMA 200-2000 4p F F InN=100% 200A 4-Pole Fixed Moulded Case Circuit Breaker

The ABB 1SDA068362R1 XT4H 250 TMA 200-2000 4p F F InN=100% is a 200A, 4-pole fixed-mount power circuit-breaker from ABB's Tmax XT4 series, engineered for transformer, generator, and installation protection in demanding industrial environments. Delivering a breaking capacity of 100 kA at 220 V AC, this moulded case circuit breaker combines robust TMA thermomagnetic trip technology with a neutral protection level of 100%, making it an ideal choice for critical power distribution systems. Compact dimensions of 140 mm × 160 mm × 82.5 mm and a weight of just 3.5 kg allow straightforward integration into switchgear panels and control cabinets.

Technical Specifications

Certifications & Standards

• RoHS: Compliant with EU Restriction of Hazardous Substances requirements
• REACH: Compliant with EU REACH chemical safety regulation
• EU Directive 2011/65/EU: Restriction of hazardous substances in electrical and electronic equipment
• Amendment 2015/863: Updated RoHS substance restrictions per EU Delegated Directive 2015/863
• IEC 60947-2: Low-voltage switchgear and controlgear — circuit-breakers standard compliance
• IEC60947-2: Verified compliance with international circuit-breaker performance standard
• EN45555: General methods for the assessment of the ability to recover resources from electrical and electronic equipment
• ATEX: Certified for use in potentially explosive atmospheres
• CE: Conformité Européenne marking — meets EU health, safety, and environmental requirements
• VDE: Verified by Verband der Elektrotechnik (German electrotechnical association) testing and certification
• WEEE: Compliant with EU Waste Electrical and Electronic Equipment Directive

Applications & Use Cases

• Transformer and generator protection in industrial power distribution systems
• Main and sub-main installation protection in commercial and industrial facilities
• Switchgear panels and motor control centers requiring high breaking capacity
• Control cabinets in manufacturing, energy, infrastructure, and process automation
• Applications in potentially explosive atmospheres where ATEX certification is mandatory
