Part number
1SDA068281R1
Model no
XT3S
$238.33 In stock · 29 Dispatch Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days. · From Türkiye

ABB 1SDA068281R1 XT3S 250 MA160 Im=960...1920 3p F F 160A 3-Pole Fixed Moulded Case Circuit Breaker

Rated current
160 A
Poles
3P
Breaking capacity
(400) 50 kA
EAN
8015644021870
Description

About the XT3S

The ABB 1SDA068281R1 — catalog number XT3S 250 MA160 Im=960...1920 3p F F — is a 160A, 3-pole fixed-mount power circuit-breaker from the Tmax XT3S series, engineered for transformer, generator, and installation protection in demanding industrial environments. Delivering a breaking capacity of 50 kA at 400 V AC, this ABB Tmax XT3S unit provides robust overcurrent and short-circuit protection where reliability is non-negotiable.

Certifications & Standards

  • RoHS: Compliant with EU Restriction of Hazardous Substances requirements
  • REACH: Compliant with EU REACH chemical safety regulation
  • EU Directive 2011/65/EU: Restriction of hazardous substances in electrical and electronic equipment
  • Amendment 2015/863: Updated RoHS substance restrictions under EU Directive 2015/863
  • IEC 60947-2: Low-voltage switchgear and controlgear — circuit-breakers standard
  • IEC60947-2: International standard for low-voltage circuit-breaker performance
  • EN45555: General methods for the assessment of the ability to recover raw materials from electrical and electronic equipment
  • ATEX: Certified for use in potentially explosive atmospheres
  • CE: Conforms to applicable EU harmonised legislation
  • VDE: Tested and certified by the German Association for Electrical, Electronic & Information Technologies
  • WEEE: Compliant with EU Waste Electrical and Electronic Equipment Directive

Applications & Use Cases

  • Transformer and generator feeder protection in industrial power distribution panels
  • Installation protection for motor control centres and switchboards
  • Short-circuit and overcurrent protection in heavy industrial automation systems
  • Control panel protection in manufacturing, oil & gas, and utilities sectors
  • Applications in potentially explosive atmospheres (ATEX-rated environments)
Specification

Full specification

62 values · Last verified 30 Oct 2026

Material Compliance 1

RoHS Information Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

Dimensions 4

Product Net Width 105 mm
Product Net Height 150 mm
Product Net Depth / Length 70 mm
Product Net Weight 1.7 kg

Additional Information 5

Circuit Breaker Type to be Associated Motor Protection
Product Main Type SACE Tmax XT
Product Name Moulded Case Circuit Breaker
Product Type Automatic Circuit Breaker
Version F
Show all 62 specifications ↓ Show less ↑52 more values in Identification, Technical, External Classifications and Standards, Logistics.

Identification 11

Part number 1SDA068281R1
Type designation XT3S
Brand ABB
Condition New, factory sealed
Source ABB and its authorised distributors
Warranty Manufacturer warranty
EAN 8015644021870
ETIM class EC000228
eCl@ss 27370409
Minimum Order Quantity 1 piece
Customs Tariff Number 85362090

Technical 27

Connecting Capacity Main Circuit Busbar 85..192 mm²
Current Type AC/DC
Electrical Durability 120 cycles per hour, 8000 cycle
Mechanical Durability 240 cycles per hour, 25000 cycle
Number of Poles 3P
Opening Time CB with SOR 30 ms, CB with UVR 30 ms
Order Multiple 1 piece
Power Loss at Rated Operating Conditions per Pole 7.9 W
Rated Current (In) 160 A
Rated Frequency (f) 50 / 60 Hz
Rated Impulse Withstand Voltage (Uimp) 8 kV
Rated Instantaneous Short-Circuit Current Setting (Ii) 960…1920 A
Rated Insulation Voltage (Ui) 800 V
Rated Operational Voltage 690 V AC, 500 V DC
Rated Service Short-Circuit Breaking Capacity (Ics) (220 V AC) 50 kA, (230 V AC) 50 kA, (240 V AC) 50 kA, (380 V AC) 27 kA, (415 V AC) 36 kA, (440 V AC) 20 kA, (500 V AC) 15 kA, (525 V AC) 10 kA, (690 V AC) 3 kA, (250 V DC) 2 Poles in Series 27 kA, (500 V DC) 3 Poles in Series 37.5 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu) (220 V AC) 85 kA, (230 V AC) 85 kA, (240 V AC) 85 kA, (380 V AC) 50 kA, (415 V AC) 50 kA, (440 V AC) 40 kA, (500 V AC) 30 kA, (525 V AC) 20 kA, (690 V AC) 6 kA, (250 V DC) 2 Poles in Series 36 kA, (500 V DC) 3 Poles in Series 50 kA
Rated Uninterrupted Current (Iu) 250 A
Rated Voltage (Ur) 690 V
Recommended Screw Driver Main Circuit M8
Release MA
Release Type M
Short-Circuit Performance Level S
Standards IEC60947-2
Sub-type XT3
Terminal Connection Type Front
Terminal Type Bolt
Tightening Torque 8 N·m

External Classifications and Standards 4

ETIM 10 EC000228 - Power circuit-breaker for trafo/generator/installation protection
UNSPSC 39120000
WEEE Category 5. Small Equipment (No External Dimension More Than 50 cm)
eClass V11.1 : 27370409

Logistics 10

Package Level 1 Units box 1 piece
Package Level 1 Width 155 mm
Package Level 1 Height 190 mm
Package Level 1 Depth / Length 155 mm
Package Level 1 Gross Weight 1.7 kg
Package Level 1 EAN 8015644021870
Shipping weight 1.7 kg
Ships from Türkiye
Dispatch 17 Nov
Stock In stock

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for 1SDA068281R1

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • CE
  • RoHS
  • ATEX
  • VDE
  • IEC60947-2
Quick answers

Questions about the XT3S

What is the rated current of XT3S?

The rated current of XT3S is 160 A.

What is the HS code of XT3S for customs?

The tariff (HS) code on file for XT3S is 85362090.

What is the EAN of XT3S?

The EAN (GTIN) of XT3S is 8015644021870.

Where does XT3S ship from, and how fast?

XT3S ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
