Part number
1SDA068221R1
Model no
XT3S
$242.52 In stock · 50+ Dispatch Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days. · From Türkiye

ABB 1SDA068221R1 XT3S 250 TMD 250-2500 3p F F 250A 3-Pole Fixed Moulded Case Circuit Breaker

Rated current
250 A
Poles
3P
Breaking capacity
(400) 50 kA
EAN
8015644021276
Description

About the XT3S

The ABB 1SDA068221R1 XT3S 250 TMD 250-2500 3p F F is a 250A, 3-pole fixed-mount power circuit-breaker engineered for trafo, generator, and installation protection in demanding industrial environments. Part of the ABB Tmax XT3S series, the XT3S 250 TMD 250-2500 3p F F delivers a breaking capacity of 50 kA at 400 V AC, making it suitable for high-fault-current applications in control panels, switchgear assemblies, and downstream distribution boards. Compact at 105 mm × 150 mm × 70 mm and weighing just 1.7 kg, this moulded case circuit-breaker combines robust protection performance with easy installation.

Certifications & Standards

  • RoHS: Compliant with the Restriction of Hazardous Substances Directive
  • REACH: Compliant with EU REACH chemical safety regulation
  • EU Directive 2011/65/EU & Amendment 2015/863: Compliant as of July 22, 2019
  • IEC 60947-2: Compliant with the international standard for low-voltage switchgear and controlgear — circuit-breakers
  • IEC60947-2: Verified compliance with IEC low-voltage circuit-breaker performance requirements
  • ATEX: Approved for use in potentially explosive atmospheres
  • CE: CE marked — meets applicable EU health, safety, and environmental requirements
  • VDE: Tested and certified by VDE (Verband der Elektrotechnik)
  • WEEE: Registered under the Waste Electrical and Electronic Equipment Directive

Applications & Use Cases

  • Transformer and generator protection in industrial power distribution
  • Installation protection in commercial and industrial switchgear panels
  • Main and sub-distribution board protection in high-fault-current environments
  • Control panel integration requiring compact, fixed-mount MCCBs
  • Applications demanding ATEX-rated circuit protection in hazardous areas
Specification

Full specification

64 values · Last verified 30 Oct 2026

Material Compliance 1

RoHS Information Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

Dimensions 4

Product Net Width 105 mm
Product Net Height 150 mm
Product Net Depth / Length 70 mm
Product Net Weight 1.7 kg

Additional Information 5

Circuit Breaker Type to be Associated Power Distribution
Product Main Type SACE Tmax XT
Product Name Moulded Case Circuit Breaker
Product Type Automatic Circuit Breaker
Version F
Show all 64 specifications ↓ Show less ↑54 more values in Identification, Technical, External Classifications and Standards, Logistics.

Identification 12

Part number 1SDA068221R1
Type designation XT3S
Brand ABB
Condition New, factory sealed
Source ABB and its authorised distributors
Warranty Manufacturer warranty
EAN 8015644021276
ETIM class EC000228
eCl@ss 27370409
E-Number (Sweden) 3182436
Minimum Order Quantity 1 piece
Customs Tariff Number 85362090

Technical 28

Connecting Capacity Main Circuit Busbar 85..192 mm²
Current Type AC/DC
Electrical Durability 120 cycles per hour, 8000 cycle
Mechanical Durability 240 cycles per hour, 25000 cycle
Number of Poles 3P
Opening Time CB with SOR 30 ms, CB with UVR 30 ms
Order Multiple 1 piece
Power Loss at Rated Operating Conditions per Pole 17.8 W
Rated Current (In) 250 A
Rated Frequency (f) 50 / 60 Hz
Rated Impulse Withstand Voltage (Uimp) 8 kV
Rated Instantaneous Short-Circuit Current Setting (Ii) 2500 A
Rated Insulation Voltage (Ui) 800 V
Rated Operational Voltage 690 V AC, 500 V DC
Rated Service Short-Circuit Breaking Capacity (Ics) (220 V AC) 50 kA, (230 V AC) 50 kA, (240 V AC) 50 kA, (380 V AC) 27 kA, (415 V AC) 36 kA, (440 V AC) 20 kA, (500 V AC) 15 kA, (525 V AC) 10 kA, (690 V AC) 3 kA, (250 V DC) 2 Poles in Series 27 kA, (500 V DC) 3 Poles in Series 37.5 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu) (220 V AC) 85 kA, (230 V AC) 85 kA, (240 V AC) 85 kA, (380 V AC) 50 kA, (415 V AC) 50 kA, (440 V AC) 40 kA, (500 V AC) 30 kA, (525 V AC) 20 kA, (690 V AC) 6 kA, (250 V DC) 2 Poles in Series 36 kA, (500 V DC) 3 Poles in Series 50 kA
Rated Uninterrupted Current (Iu) 250 A
Rated Voltage (Ur) 690 V
Recommended Screw Driver Main Circuit M8
Release TMD
Release Type TM
Setting Range 175...250 A
Short-Circuit Performance Level S
Standards IEC60947-2
Sub-type XT3
Terminal Connection Type Front
Terminal Type Bolt
Tightening Torque 8 N·m

External Classifications and Standards 4

ETIM 10 EC000228 - Power circuit-breaker for trafo/generator/installation protection
UNSPSC 39120000
WEEE Category 5. Small Equipment (No External Dimension More Than 50 cm)
eClass V11.1 : 27370409

Logistics 10

Package Level 1 Units box 1 piece
Package Level 1 Width 155 mm
Package Level 1 Height 190 mm
Package Level 1 Depth / Length 155 mm
Package Level 1 Gross Weight 1.71 kg
Package Level 1 EAN 8015644021276
Shipping weight 1.71 kg
Ships from Türkiye
Dispatch 17 Nov
Stock In stock

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for 1SDA068221R1

No documents are on file for this part yet.

Ask us for the datasheet
Certifications

Certifications and standards

  • CE
  • RoHS
  • ATEX
  • VDE
  • IEC60947-2
Quick answers

Questions about the XT3S

What is the rated current of XT3S?

The rated current of XT3S is 250 A.

What is the HS code of XT3S for customs?

The tariff (HS) code on file for XT3S is 85362090.

What is the EAN of XT3S?

The EAN (GTIN) of XT3S is 8015644021276.

Where does XT3S ship from, and how fast?

XT3S ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
