ABB 1SDA067769R1 XT2S 160 MA 100 Im=600...1400 3p F F 100A 3-Pole Fixed Moulded Case Circuit Breaker

The ABB 1SDA067769R1 XT2S 160 MA 100 Im=600...1400 3p F F is a 100A 3-pole fixed-mount power circuit-breaker engineered for transformer, generator, and installation protection applications. Part of the ABB Tmax XT2 series, it delivers a breaking capacity of 85 kA at 220 V AC, making it a robust solution for demanding industrial environments where reliable short-circuit and overload protection is essential.

Technical Specifications

Certifications & Standards

• RoHS: Compliant with EU Restriction of Hazardous Substances requirements
• REACH: Compliant with EU REACH chemical safety regulation
• EU Directive 2011/65/EU: Restriction of hazardous substances in electrical and electronic equipment
• Amendment 2015/863: Updated RoHS substance restrictions per EU Amendment 2015/863
• IEC 60947-2: Meets international standard for low-voltage switchgear — circuit-breakers
• IEC60947-2: Full compliance verified under IEC low-voltage switchgear standard
• ATEX: Approved for use in potentially explosive atmospheres
• CE: Carries CE marking for conformity with European safety directives
• VDE: Certified by VDE German electrotechnical testing and certification institute
• WEEE: Registered under the Waste Electrical and Electronic Equipment directive

Applications & Use Cases

• Transformer protection in industrial power distribution panels
• Generator protection in standby and prime power installations
• Installation protection in commercial and industrial control panels
• Short-circuit and magnetic trip protection in demanding automation environments
• Fixed-mount switchgear assemblies requiring compact 3-pole MCCB solutions
