ABB 1SDA067460R1 XT1H 160 TMD 100-1000 4p F F 100A 4-Pole 100kA Fixed Molded Case Circuit Breaker

The ABB 1SDA067460R1 XT1H 160 TMD 100-1000 4p F F is a 4-pole molded case circuit breaker from the Tmax XT1 series, delivering a 100 kA breaking capacity at 220 V AC with an adjustable thermal-magnetic trip unit covering 100–1000 A. Designed for fixed mounting in industrial power distribution panels, the XT1H 160 TMD 100-1000 4p F F provides reliable overload protection and short circuit protection in demanding environments, including those classified under ATEX directives. Weighing just 1.44 kg, this compact MCCB is engineered for high-density switchgear applications.

Technical Specifications

Certifications & Standards

• RoHS: Compliant with EU Restriction of Hazardous Substances directive
• REACH: Compliant with EU REACH regulation on chemical substances
• IEC 60947-2: Meets international standard for low-voltage switchgear and circuit breakers
• ATEX: Approved for use in potentially explosive atmospheres
• CE: Certified for the European Economic Area market
• VDE: Verified by VDE (Verband der Elektrotechnik) to German electrical engineering standards

Applications & Use Cases

• Industrial power distribution panels and switchboards requiring high breaking capacity
• Protection of motor feeders and branch circuits in manufacturing facilities
• Main and sub-main circuit protection in commercial and heavy-industry installations
• ATEX-classified hazardous-area installations (oil & gas, chemical processing, mining)
• 4-wire distribution systems requiring 4-pole isolation and short circuit protection
• Applications demanding adjustable thermal-magnetic trip for flexible overload protection
