Part number
1SDA067415R1
Model no
XT1N
$124.60 In stock · 50+ Dispatch Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days. · From Türkiye

ABB 1SDA067415R1 XT1N 160 TMD 80-800 3p F F 80A 3-Pole Fixed Moulded Case Circuit Breaker

Rated current
80 A
Poles
3P
Breaking capacity
(400) 36 kA
EAN
8015644013097
Other ratings in ABB Tmax XT All 6 ratings ↓
Neighbouring ratings in the same series
Motor power kW Rated current In (A) Part number Stock Price
40 1SDA067412R1 In stock $124.60
63 1SDA067414R1 In stock $124.60
80 1SDA067415R1This part In stock $124.60
125 1SDA067417R1 In stock $142.11
160 1SDA067418R1 In stock $146.30
Description

About the XT1N

The ABB 1SDA067415R1 XT1N 160 TMD 80-800 3p F F is a 3-pole, 80 A fixed-mount moulded case circuit breaker from the Tmax XT1 series, engineered for reliable short-circuit and overload protection of transformers, generators, and general installations. Featuring a TMD (Thermal-Magnetic trip unit with adjustable thermal and fixed magnetic release), this compact breaker — measuring just 76.2 × 130 × 70 mm and weighing 1.1 kg — delivers robust performance in demanding industrial environments. The XT1N 160 TMD 80-800 3p F F is fully compliant with IEC 60947-2 and carries CE, VDE, ATEX, and UL 2799 certifications, making it suitable for international projects.

Certifications & Standards

  • CE: Complies with applicable EU harmonised directives for electrical equipment
  • IEC 60947-2: Meets the international standard for low-voltage circuit breakers
  • VDE: Certified by the German Association for Electrical Engineering
  • ATEX: Approved for use in potentially explosive atmospheres
  • UL 2799: Listed to UL standard 2799 for electrical distribution switchboards
  • RoHS: Compliant with EU Restriction of Hazardous Substances Directive
  • REACH: Compliant with EU REACH regulation on chemical substances
  • EU Directive 2011/65/EU: Meets the original RoHS2 directive requirements
  • Amendment 2015/863: Updated RoHS substance restrictions including four additional phthalates
  • EN 45555: Compliant with general methods for the assessment of the ability to recycle and recover electrical and electronic equipment
  • WEEE: Registered under the EU Waste Electrical and Electronic Equipment directive

Applications & Use Cases

  • Transformer secondary-side protection in industrial power distribution boards
  • Generator output circuit protection in standby and prime-power applications
  • Feeder and branch circuit protection within MCC (Motor Control Centre) panels
  • Installation protection in commercial buildings, manufacturing plants, and infrastructure projects
  • Use in potentially explosive atmospheres where ATEX-rated components are mandatory
Specification

Full specification

64 values · Last verified 30 Oct 2026

Material Compliance 1

RoHS Information Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

Dimensions 4

Product Net Width 76.2 mm
Product Net Height 130 mm
Product Net Depth / Length 70 mm
Product Net Weight 1.1 kg

Additional Information 5

Circuit Breaker Type to be Associated Power Distribution
Product Main Type SACE Tmax XT
Product Name Moulded Case Circuit Breaker
Product Type Automatic Circuit Breaker
Version F
Show all 64 specifications ↓ Show less ↑54 more values in Identification, Technical, External Classifications and Standards, Logistics.

Identification 12

Part number 1SDA067415R1
Type designation XT1N
Brand ABB
Condition New, factory sealed
Source ABB and its authorised distributors
Warranty Manufacturer warranty
EAN 8015644013097
ETIM class EC000228
eCl@ss 27370409
E-Number (Sweden) 3182430
Minimum Order Quantity 1 piece
Customs Tariff Number 85362090

Technical 28

Connecting Capacity Main Circuit Busbar 45.5 ... 80 mm²
Current Type AC/DC
Electrical Durability 120 cycles per hour, 8000 cycle
Mechanical Durability 240 cycles per hour, 25000 cycle
Number of Poles 3P
Opening Time CB with SOR 30 ms, CB with UVR 30 ms
Order Multiple 1 piece
Power Loss at Rated Operating Conditions per Pole 4.8 W
Rated Current (In) 80 A
Rated Frequency (f) 50 / 60 Hz
Rated Impulse Withstand Voltage (Uimp) 8 kV
Rated Instantaneous Short-Circuit Current Setting (Ii) 800 A
Rated Insulation Voltage (Ui) 800 V
Rated Operational Voltage 690 V AC, 500 V DC
Rated Service Short-Circuit Breaking Capacity (Ics) (220 V AC) 50 kA, (230 V AC) 50 kA, (240 V AC) 50 kA, (380 V AC) 36 kA, (415 V AC) 36 kA, (440 V AC) 18 kA, (500 V AC) 15 kA, (525 V AC) 11 kA, (690 V AC) 5 kA, (250 V DC) 2 Poles in Series 36 kA, (500 V DC) 3 Poles in Series 36 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu) (220 V AC) 65 kA, (230 V AC) 65 kA, (240 V AC) 65 kA, (380 V AC) 36 kA, (415 V AC) 36 kA, (440 V AC) 36 kA, (500 V AC) 30 kA, (525 V AC) 22 kA, (690 V AC) 6 kA, (250 V DC) 2 Poles in Series 36 kA, (500 V DC) 3 Poles in Series 36 kA
Rated Uninterrupted Current (Iu) 160 A
Rated Voltage (Ur) 690 V
Recommended Screw Driver Main Circuit M6
Release TMD
Release Type TM
Setting Range 56...80 A
Short-Circuit Performance Level N
Standards IEC60947-2
Sub-type XT1
Terminal Connection Type Front
Terminal Type Bolt
Tightening Torque 6 N·m

External Classifications and Standards 4

ETIM 10 EC000228 - Power circuit-breaker for trafo/generator/installation protection
UNSPSC 39120000
WEEE Category 5. Small Equipment (No External Dimension More Than 50 cm)
eClass V11.1 : 27370409

Logistics 10

Package Level 1 Units box 1 piece
Package Level 1 Width 128 mm
Package Level 1 Height 135 mm
Package Level 1 Depth / Length 143 mm
Package Level 1 Gross Weight 1.134 kg
Package Level 1 EAN 8015644013097
Shipping weight 1.134 kg
Ships from Türkiye
Dispatch 17 Nov
Stock In stock

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for 1SDA067415R1

No documents are on file for this part yet.

Ask us for the datasheet
Other ratings

All 6 ratings in ABB Tmax XT

ABB ABB Tmax XT series page →
Other ratings in the same series
Motor power Rated current Part number Model no Stock Dispatch Price Add to cart
32 A 1SDA067411R1 XT1N In stock $124.60
40 A 1SDA067412R1 XT1N In stock $124.60
63 A 1SDA067414R1 XT1N In stock $124.60
80 A 1SDA067415R1 This part XT1N In stock $124.60
125 A 1SDA067417R1 XT1N In stock $142.11
160 A 1SDA067418R1 XT1N In stock $146.30
