- Part number
- 1SCA105008R1001
- Model no
- OT100F3C
Critical stock
Dispatch
Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days.
· From Türkiye
0
- DNV
- RoHS
ABB 1SCA105008R1001 OT100F3C 3P 100A Base Mount Change-Over Switch Disconnector
Description
About the OT100F3C
About the OT100F3C
The ABB OT100F3C (SKU: 1SCA105008R1001) is a 3-pole 100A change-over switch disconnector designed for reliable source switching and load isolation in low-voltage industrial installations. Rated to IEC60947-3 and UL 98 standards, this base-mount disconnector delivers robust performance in control panels, distribution boards, and critical power changeover applications. With compact dimensions of 140 × 100 × 86 mm and a weight of just 0.9 kg, the OT100F3C integrates efficiently into space-constrained enclosures.
Certifications & Standards
- RoHS: Compliant with EU Restriction of Hazardous Substances Directive
- REACH: Compliant with EU REACH regulation for chemical safety
- DNV: Approved by Det Norske Veritas for marine and offshore applications
- UL 98 / IEC60947-3: Certified to UL 98 and IEC60947-3 for enclosed and open switches
- IEC60947-3: Compliant with IEC standard for switches, disconnectors, and switch-disconnectors
- IEC60947: Compliant with the broader IEC low-voltage switchgear and controlgear standard
- CSA: Certified to Canadian Standards Association requirements
- CE: Marked for conformity with applicable EU directives
- WEEE: Registered under the EU Waste Electrical and Electronic Equipment Directive
Applications & Use Cases
- Source changeover in emergency and standby power systems
- Load isolation and disconnection in industrial control panels
- Distribution boards in commercial and industrial buildings
- Marine and offshore installations (DNV approved)
- Generator changeover switching in critical infrastructure
Specification
Full specification
Material Compliance 1
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
|---|
Environmental 2
| Degree of Protection | Front IP20 |
|---|---|
| Pollution Degree | 3 |
Dimensions 4
| Product Net Width | 140 mm, 5.51 in |
|---|---|
| Product Net Height | 100 mm, 3.94 in |
| Product Net Depth / Length | 86 mm, 3.39 in |
| Product Net Weight | 0.9 kg |
Show all 60 specifications ↓ Show less ↑53 more values in Identification, Technical, Technical UL/CSA, External Classifications and Standards, Logistics.
Identification 12
| Part number | 1SCA105008R1001 |
|---|---|
| Type designation | OT100F3C |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 6417019391397 |
| ETIM class | EC000216 |
| eCl@ss | 27371403 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85365080 |
| Country of Origin | Finland |
Technical 24
| Cable Cross-Section | 10 ... 70 mm² |
|---|---|
| Conventional Free-air Thermal Current (Ith) | Θ = 40 °C 115 A |
| Conventional Thermal Current (Ithe) | Fully Enclosed 115 A |
| Distance Between Phases | Standard |
| Handle Color | Black |
| Mechanical Durability | 6000 cycle |
| Mounting Type | Base mounting |
| Number of Poles | 3P |
| Operating Mode | Front |
| Position of Line Terminals | Top In - Bottom Out, Bottom In - Top Out |
| Power Loss | at Rated Operating Conditions per Pole 4 W |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 750 V |
| Rated Operational Current AC-21A (Ie) | (380 ... 415 V) 100 A, (500 V) 100 A, (690 V) 100 A |
| Rated Operational Current AC-22A (Ie) | (380 ... 415 V) 100 A, (500 V) 100 A, (690 V) 100 A |
| Rated Operational Current AC-23A (Ie) | (380 ... 415 V) 80 A, (500 V) 60 A, (690 V) 40 A |
| Rated Operational Power AC-23A (Pe) | (380 ... 415 V) 37 kW, (500 V) 37 kW, (690 V) 37 kW |
| Rated Operational Voltage | Main Circuit 750 V |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 1 s 2.5 kiloampere rms |
| Standards | UL 98 / IEC60947-3 |
| Switches Operating Mechanism | Mechanism on Top of the Switch |
| Terminal Type | Screw Terminals |
| Tightening Torque | acc. IEC 60947-1 6 N·m |
| Transition Type | Open |
Technical UL/CSA 2
| Ampere Rating | 100 A |
|---|---|
| Horsepower Rating UL/CSA | (acc. to UL 200 V) 30 Hp, (acc. to UL 208 V) 30 Hp, (acc. to UL 240 V) 30 Hp, (acc. to UL 480 V) 50 Hp, (acc. to UL 600 V) 50 Hp |
External Classifications and Standards 5
| ETIM 10 | EC000216 - Switch disconnector (AC) |
|---|---|
| UNSPSC | 39122233 |
| eClass | V11.1 : 27371403 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| E-Number (Sweden) | 3171265 |
Logistics 10
| Package Level 1 Units | box 1 box |
|---|---|
| Package Level 1 Width | 102 mm, 4.02 in |
| Package Level 1 Depth / Length | 205 mm, 8.07 in |
| Package Level 1 Height | 103 mm, 4.06 in |
| Package Level 1 Gross Weight | 0.9 kg, 1.98 lb |
| Package Level 1 EAN | 6417019391397 |
| Shipping weight | 0.9 kg |
| Ships from | Türkiye |
| Dispatch | 16 Nov |
| Stock | Critical stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 1SCA105008R1001
No documents are on file for this part yet.
Ask us for the datasheet
Certifications
Certifications and standards
- DNV
- RoHS
- UL 98 / IEC60947-3
Quick answers
Questions about the OT100F3C
What is the rated current of OT100F3C?
The rated current of OT100F3C is 100 A.
What is the HS code of OT100F3C for customs?
The tariff (HS) code on file for OT100F3C is 85365080.
What is the EAN of OT100F3C?
The EAN (GTIN) of OT100F3C is 6417019391397.
Where does OT100F3C ship from, and how fast?
OT100F3C ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
