Part number
1SCA022627R7830
Model no
OFAF4H1250
$213.10 On request Dispatch — · From TürkiyeGet a Quote
OFAF

ABB 1SCA022627R7830 OFAF4H1250 HRC Fuse Link 1250A 500VAC/250VDC 120kA 4-Pole

Rated current
1250 A
Rated operational voltage
500 – 250 V DC
EAN
6417019206202
Other ratings in OFAF All 2 ratings ↓
Neighbouring ratings in the same series
Motor power kW Rated current In (A) Part number Stock Price
1000 1SCA022627R7750 Low stock $189.19
1250 1SCA022627R7830This part On request $213.10
Description

About the OFAF4H1250

The ABB OFAF4H1250 HRC fuse link (SKU: 1SCA022627R7830) is a high-rupturing-capacity fuse designed for demanding industrial power distribution and overcurrent protection applications. Rated at 1250A with a maximum voltage of 500V AC / 250V DC and an exceptional breaking capacity of 120 kA AC (70 kA DC), the OFAF4H1250 delivers reliable fault protection in control panels, switchgear, and motor circuits where high short-circuit currents must be safely interrupted.

Certifications & Standards

  • IEC 60269: Compliant with the international standard for low-voltage fuses, ensuring safe and reliable overcurrent protection performance.
  • CE: Certified to meet European safety, health, and environmental protection requirements for the EU market.
  • RoHS: Compliant with EU Directive 2011/65/EU on the restriction of hazardous substances in electrical and electronic equipment.
  • REACH: Compliant with EU Regulation (EC) No 1907/2006 concerning the registration, evaluation, authorisation and restriction of chemicals.
  • EU Directive 2011/65/EU & Amendment 2015/863: Meets the updated RoHS 2 directive including the revised restricted substances list introduced by Delegated Directive 2015/863.
  • WEEE: Compliant with EU Directive 2012/19/EU on waste electrical and electronic equipment, supporting responsible end-of-life recycling.

Applications & Use Cases

  • Industrial switchgear and motor control centres (MCCs) requiring high short-circuit protection at 1250A
  • Power distribution boards and busbars in manufacturing plants and process industries
  • Protection of large motors, transformers, and capacitor banks
  • Control panels operating at up to 500V AC in heavy industrial environments
  • DC distribution systems operating at up to 250V DC where 70 kA breaking capacity is required
Specification

Full specification

39 values · Last verified 30 Oct 2026

Material Compliance 1

RoHS Information Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

Dimensions 4

Product Net Width 68 mm
Product Net Height 200 mm
Product Net Depth / Length 119 mm
Product Net Weight 2 kg

Technical 8

Fuse Size NH4
Fuse System DIN
Fuse Type gG
Power Loss at Rated Current 87 W, Total 87 W
Rated Current (In) 1250 A
Rated Voltage (Ur) 500 V
Standards IEC 60269
Utilization Category gL/gG (Cable protection/equipment protection)
Show all 39 specifications ↓ Show less ↑26 more values in Identification, External Classifications and Standards, Logistics.

Identification 12

Part number 1SCA022627R7830
Type designation OFAF4H1250
Brand ABB
Condition New, factory sealed
Source ABB and its authorised distributors
Warranty Manufacturer warranty
EAN 6417019206202
ETIM class EC000055
eCl@ss 27142005
Minimum Order Quantity 1 piece
Customs Tariff Number 85361090
Country of Origin Hungary

External Classifications and Standards 4

ETIM 10 EC000055 - Knife blade fuse
UNSPSC 39121600
eClass V11.1 : 27142005
WEEE Category 5. Small Equipment (No External Dimension More Than 50 cm)

Logistics 10

Package Level 1 Units box 1 piece
Package Level 1 Width 68 mm
Package Level 1 Depth / Length 200 mm
Package Level 1 Height 119 mm
Package Level 1 Gross Weight 2.1 kg
Package Level 1 EAN 6417019206202
Shipping weight 2.1 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for 1SCA022627R7830

No documents are on file for this part yet.

Ask us for the datasheet
Other ratings

All 2 ratings in OFAF

Other ratings in the same series
Motor power Rated current Part number Model no Stock Dispatch Price Add to cart
1000 A 1SCA022627R7750 OFAF4H1000 Low stock $189.19
1250 A 1SCA022627R7830 This part OFAF4H1250 On request — $213.10 Quote
Certifications

Certifications and standards

  • CE
  • RoHS
  • IEC 60269
Quick answers

Questions about the OFAF4H1250

What is the rated current of OFAF4H1250?

The rated current of OFAF4H1250 is 1250 A.

Which supply voltage is OFAF4H1250 rated for?

The rated operational voltage of OFAF4H1250 is 500 – 250 V DC.

What is the HS code of OFAF4H1250 for customs?

The tariff (HS) code on file for OFAF4H1250 is 85361090.

What is the EAN of OFAF4H1250?

The EAN (GTIN) of OFAF4H1250 is 6417019206202.

Where does OFAF4H1250 ship from, and how fast?

OFAF4H1250 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
