ABB 1SCA022627R7080 OFAF3H500 HRC Fuselink 500A 500VAC/250VDC 120kA 3-Pole
| Motor power kW | Rated current In (A) | Part number | Stock | Price |
|---|---|---|---|---|
| 450 | 1SCA022627R6940 | Low stock | $26.17 | |
| 500 | 1SCA022627R7080This part | In stock | $26.17 |
Description
About the OFAF3H500
About the OFAF3H500
The ABB OFAF3H500 (SKU: 1SCA022627R7080) is a high-rupturing-capacity (HRC) fuselink rated at 500A and 500VAC / 250VDC, delivering a breaking capacity of 120 kA AC and 80 kA DC for robust short-circuit protection in demanding industrial installations. Part of ABB's OFAF series, the OFAF3H500 is engineered for use in switchboards, distribution panels, and motor protection circuits where reliable overcurrent protection is critical. Compliant with IEC 60269 and CE-marked, it meets the most stringent European safety and environmental standards.
Certifications & Standards
- IEC 60269: Compliant with the international standard for low-voltage fuses, ensuring reliable performance and interchangeability
- CE: Certified for sale and use within the European Economic Area
- RoHS: Compliant with EU Directive 2011/65/EU on the restriction of hazardous substances, including Amendment 2015/863
- REACH: Compliant with EU REACH regulation (EC) No 1907/2006 on chemical substance safety
- WEEE: Registered under the Waste Electrical and Electronic Equipment Directive for responsible end-of-life disposal
Applications & Use Cases
- Short-circuit and overcurrent protection in LV switchboards and distribution panels
- Motor branch circuit protection in industrial control panels
- Protection of busbars and cable runs in manufacturing and process automation facilities
- Suitable for DC applications up to 250 VDC with 80 kA breaking capacity
- Compatible with ABB OFAF-series fuse bases and switch-fuse combinations
Specification
Full specification
Material Compliance 1
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
|---|
Dimensions 4
| Product Net Width | 70 mm |
|---|---|
| Product Net Height | 150 mm |
| Product Net Depth / Length | 84 mm |
| Product Net Weight | 1 kg |
Technical 8
| Fuse Size | NH3 |
|---|---|
| Fuse System | DIN |
| Fuse Type | gG |
| Power Loss | at Rated Current 43 W, Total 43 W |
| Rated Current (In) | 500 A |
| Rated Voltage (Ur) | 500 V |
| Standards | IEC 60269 |
| Utilization Category | gL/gG (Cable protection/equipment protection) |
Show all 40 specifications ↓ Show less ↑27 more values in Identification, External Classifications and Standards, Logistics.
Identification 12
| Part number | 1SCA022627R7080 |
|---|---|
| Type designation | OFAF3H500 |
| Brand | ABB |
| Condition | New, factory sealed |
| Source | ABB and its authorised distributors |
| Warranty | Manufacturer warranty |
| EAN | 6417019206165 |
| ETIM class | EC000055 |
| eCl@ss | 27142005 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85361090 |
| Country of Origin | Hungary |
External Classifications and Standards 5
| ETIM 10 | EC000055 - Knife blade fuse |
|---|---|
| UNSPSC | 39121600 |
| eClass | V11.1 : 27142005 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| E-Number (Sweden) | 2040216 |
Logistics 10
| Package Level 1 Units | box 1 piece |
|---|---|
| Package Level 1 Width | 70 mm |
| Package Level 1 Depth / Length | 150 mm |
| Package Level 1 Height | 84 mm |
| Package Level 1 Gross Weight | 1.05 kg |
| Package Level 1 EAN | 6417019206165 |
| Shipping weight | 1.05 kg |
| Ships from | Türkiye |
| Dispatch | 18 Nov |
| Stock | In stock |
Source: manufacturer data · Last verified: 30 Oct 2026
Documents
Documents for 1SCA022627R7080
No documents are on file for this part yet.
Ask us for the datasheet
Other ratings
All 2 ratings in OFAF
| Motor power | Rated current | Part number | Model no | Stock | Dispatch | Price | Add to cart |
|---|---|---|---|---|---|---|---|
| 450 A | 1SCA022627R6940 | OFAF3H450 | Low stock | $26.17 | |||
| 500 A | 1SCA022627R7080 This part | OFAF3H500 | In stock | $26.17 |
