Part number
1SCA022627R6940
Model no
OFAF3H450
$26.17 Low stock Dispatch Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days. · From Türkiye
OFAF

ABB 1SCA022627R6940 OFAF3H450 450A 500VAC/250VDC 120kA 3-Pole HRC Fuse Link Fuselink

Rated current
450 A
Rated operational voltage
500 – 250 V DC
EAN
6417019206158
Other ratings in OFAF All 2 ratings ↓
Neighbouring ratings in the same series
Motor power kW Rated current In (A) Part number Stock Price
450 1SCA022627R6940This part Low stock $26.17
500 1SCA022627R7080 In stock $26.17
Description

About the OFAF3H450

The ABB OFAF3H450 (SKU: 1SCA022627R6940) is a high-rupturing-capacity (HRC) fuse link rated at 450A and 500VAC / 250VDC, delivering a breaking capacity of 120 kA AC and 80 kA DC for robust short-circuit protection in industrial power distribution systems. Part of ABB's OFAF series, the OFAF3H450 is engineered to protect cables, busbars, and downstream equipment in switchgear panels, motor control centres, and heavy industrial applications where reliable overcurrent interruption is critical.

Certifications & Standards

  • IEC 60269: Complies with the international standard for low-voltage fuses, ensuring reliable performance and interchangeability
  • CE: Meets European Conformity requirements for electrical equipment placed on the EU market
  • RoHS: Compliant with EU Directive 2011/65/EU on restriction of hazardous substances in electrical and electronic equipment
  • REACH: Compliant with EU REACH regulation concerning the registration, evaluation, and authorisation of chemicals
  • EU Directive 2011/65/EU & Amendment 2015/863: Fully compliant with the RoHS recast directive and its updated substance thresholds
  • WEEE: Registered under the Waste Electrical and Electronic Equipment directive for proper end-of-life recycling

Applications & Use Cases

  • Short-circuit and overcurrent protection in industrial switchgear and distribution boards
  • Protection of cables, busbars, and transformers in motor control centres (MCCs)
  • Heavy industrial environments including manufacturing plants, process industries, and utilities
  • DC bus protection in renewable energy and battery storage systems (250 VDC rated)
  • Replacement and upgrade of existing HRC fuse links in ABB OFAF-compatible fuse bases
Specification

Full specification

39 values · Last verified 30 Oct 2026

Material Compliance 1

RoHS Information Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

Dimensions 4

Product Net Width 70 mm
Product Net Height 150 mm
Product Net Depth / Length 84 mm
Product Net Weight 1 kg

Technical 8

Fuse Size NH3
Fuse System DIN
Fuse Type gG
Power Loss at Rated Current 38 W, Total 38 W
Rated Current (In) 450 A
Rated Voltage (Ur) 500 V
Standards IEC 60269
Utilization Category gL/gG (Cable protection/equipment protection)
Show all 39 specifications ↓ Show less ↑26 more values in Identification, External Classifications and Standards, Logistics.

Identification 12

Part number 1SCA022627R6940
Type designation OFAF3H450
Brand ABB
Condition New, factory sealed
Source ABB and its authorised distributors
Warranty Manufacturer warranty
EAN 6417019206158
ETIM class EC000055
eCl@ss 27142005
Minimum Order Quantity 1 piece
Customs Tariff Number 85361090
Country of Origin Hungary

External Classifications and Standards 4

ETIM 10 EC000055 - Knife blade fuse
UNSPSC 39121600
eClass V11.1 : 27142005
WEEE Category 5. Small Equipment (No External Dimension More Than 50 cm)

Logistics 10

Package Level 1 Units box 1 piece
Package Level 1 Width 70 mm
Package Level 1 Depth / Length 150 mm
Package Level 1 Height 84 mm
Package Level 1 Gross Weight 1.05 kg
Package Level 1 EAN 6417019206158
Shipping weight 1.05 kg
Ships from Türkiye
Dispatch 18 Nov
Stock Low stock

Source: manufacturer data · Last verified: 30 Oct 2026

Documents

Documents for 1SCA022627R6940

No documents are on file for this part yet.

Ask us for the datasheet
Other ratings

All 2 ratings in OFAF

Other ratings in the same series
Motor power Rated current Part number Model no Stock Dispatch Price Add to cart
450 A 1SCA022627R6940 This part OFAF3H450 Low stock $26.17
500 A 1SCA022627R7080 OFAF3H500 In stock $26.17
Certifications

Certifications and standards

  • CE
  • RoHS
  • IEC 60269
Quick answers

Questions about the OFAF3H450

What is the rated current of OFAF3H450?

The rated current of OFAF3H450 is 450 A.

Which supply voltage is OFAF3H450 rated for?

The rated operational voltage of OFAF3H450 is 500 – 250 V DC.

What is the HS code of OFAF3H450 for customs?

The tariff (HS) code on file for OFAF3H450 is 85361090.

What is the EAN of OFAF3H450?

The EAN (GTIN) of OFAF3H450 is 6417019206158.

Where does OFAF3H450 ship from, and how fast?

OFAF3H450 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
