ABB 1SBL177001R1301 AF16-30-01-13 3-Pole 30A 690V 7.5kW AF Series Power Contactor AC Switching 100-250V Coil

The ABB AF16-30-01-13 power contactor (SKU: 1SBL177001R1301) is a 3-pole AC switching contactor rated at 30 A and 690 V, delivering 7.5 kW motor switching capability with a wide-range 100–250 V AC/DC coil. Designed for demanding industrial automation and control panel applications, the AF16-30-01-13 belongs to ABB's proven AF series and complies with IEC 60947-4, UL, CSA, and a comprehensive set of global certifications — making it suitable for international deployments.

Technical Specifications

Certifications & Standards

• CE: European conformity marking for electrical equipment
• UKCA: UK Conformity Assessed marking
• UL: Underwriters Laboratories listed
• UL 60947-4-1: UL standard for low-voltage AC contactors
• UL 60335-2-40: UL standard for HVAC equipment safety (LZGH2A2L)
• CSA: Canadian Standards Association certified
• CSA C22.2 No. 60947-4-1: CSA standard for low-voltage contactors
• CSA C22.2 No. 60335-2-40: CSA HVAC equipment safety standard (LZGH2A2L)
• CSA C22.2 No. 60335: CSA household & similar appliances standard
• CSA C22.2 No. 60947: CSA low-voltage switchgear & controlgear standard
• CCC: China Compulsory Certification
• CQC: China Quality Certification Centre
• ABS: American Bureau of Shipping type approval
• BV: Bureau Veritas marine/industrial certification
• CB: IECEE CB Scheme international safety certificate
• IEC 60947-1 / EN 60947-1: General rules for low-voltage switchgear & controlgear
• IEC 60947-4 / EN 60947-4: Contactors and motor starters standard
• IEC/EN 60947-1: Low-voltage switchgear general rules (consolidated reference)
• IEC/EN 60947-4: Low-voltage contactors and motor starters (consolidated reference)
• IEC 60947-5: Control circuit devices and switching elements
• IEC 60068-2: Environmental testing standard
• REACH: EU chemical safety regulation compliance
• RoHS: Restriction of hazardous substances compliance
• WEEE: Waste electrical & electronic equipment directive compliance

Applications & Use Cases

• Motor switching and control in industrial automation systems
• Control panel and MCC (motor control centre) assemblies
• HVAC and refrigeration equipment switching
• Pump, fan, and conveyor motor starting
• International installations requiring multi-standard certification (UL, CSA, IEC, CCC)
