ABB 1SBL156001R2110 AF12Z-30-10-21 3-Pole 28A 690V 24-60V AC/DC Coil AF Series Power Contactor AC Switching

The ABB AF12Z-30-10-21 power contactor (SKU: 1SBL156001R2110) is a 3-pole AC switching contactor rated at 28 A and 690 V, designed for demanding industrial motor control and automation applications. Part of ABB's proven AF series, this contactor features a wide-range coil accepting 24–60 V AC (50/60 Hz) and 20–60 V DC, enabling flexible integration across diverse control voltage architectures. Compact at 45 × 86 × 77 mm and weighing only 0.31 kg, the AF12Z-30-10-21 delivers reliable switching performance at up to 5.5 kW.

Technical Specifications

Certifications & Standards

• CE: Conformité Européenne — meets EU safety, health, and environmental requirements
• UL: Underwriters Laboratories listed for North American market
• CSA: Canadian Standards Association certified
• CCC: China Compulsory Certification
• CQC: China Quality Certification Centre
• ABS: American Bureau of Shipping approved
• BV: Bureau Veritas certified
• CB: IEC CB Scheme certification for international market acceptance
• UL 60335-2-40: Standard for household and similar electrical appliances — heating and cooling equipment
• UL 60335-2-40 LZGH2A2L: UL listing under file LZGH2A2L
• UL 60947-4-1: UL standard for low-voltage switchgear — electromechanical contactors and motor starters
• CSA C22.2 No. 60335-2-40: Canadian standard for heating and cooling equipment
• CSA C22.2 No. 60335-2-40 LZGH2A2L: CSA listing under file LZGH2A2L
• CSA C22.2 No. 60947-4-1: Canadian standard for contactors and motor starters
• CSA C22.2 No. 60335: Canadian standard series for electrical appliances
• CSA C22.2 No. 60947: Canadian standard series for low-voltage switchgear
• IEC 60947-1 / EN 60947-1: General rules for low-voltage switchgear and controlgear
• IEC 60947-4 / EN 60947-4: Contactors and motor starters
• IEC/EN 60947-1: Low-voltage switchgear — general rules
• IEC/EN 60947-4: Low-voltage switchgear — contactors and motor starters
• IEC 60947-5: Control circuit devices and switching elements
• IEC 60947-4 (IEC60947-4): Contactors and motor starters
• IEC 60947-5 (IEC60947-5): Control circuit devices
• IEC 60715 (IEC60715): Dimensions of low-voltage switchgear for DIN rail mounting
• IEC 60529 (IEC60529): Degrees of protection provided by enclosures (IP Code)
• IEC 60947-1 (IEC60947-1): Low-voltage switchgear — general rules
• IEC 60068-2-27: Environmental testing — shock
• EN 45555-92: General methods for assessing the recyclability and recoverability of energy-related products
• REACH: EU regulation on registration, evaluation, authorisation and restriction of chemicals
• RoHS: Restriction of Hazardous Substances — compliant with EU Directive 2011/65/EU
• WEEE: Waste Electrical and Electronic Equipment Directive compliant
• UKCA: UK Conformity Assessed — meets UK post-Brexit market requirements

Applications & Use Cases

• Motor starting and stopping in industrial automation and control panels
• HVAC equipment control including compressors and fan motors up to 5.5 kW
• Machine tool and conveyor system switching
• Pump and compressor control in process industries
• Building automation and facility management systems
• Reversing starter configurations when paired with a second contactor
