ABB 1SBH137001R1140 NF40E-11 4-Pole 24-60V AC/DC Contactor Relay

The ABB NF40E-11 contactor relay (SKU: 1SBH137001R1140) is a 4-pole auxiliary relay from the ABB NF series, designed for control circuit switching in industrial automation and control panel applications. Rated for a wide coil voltage range of 24–60V AC (50/60 Hz) and 20–60V DC, the NF40E-11 offers versatile integration into both AC and DC control systems. With compact dimensions of 87 × 79 × 47 mm and a lightweight 0.27 kg body, it is optimized for space-efficient DIN rail installations.

Technical Specifications

Certifications & Standards

• CE: European Conformity — meets EU safety, health, and environmental requirements
• UKCA: UK Conformity Assessed — compliant for the UK market post-Brexit
• CCC: China Compulsory Certification — approved for the Chinese market
• UL: Underwriters Laboratories listed — North American safety certification
• DNV: Det Norske Veritas — marine and offshore type approval
• LR: Lloyd's Register — marine equipment approval
• RINA: Registro Italiano Navale — Italian naval classification society approval
• RMRS: Russian Maritime Register of Shipping — marine type approval
• KC: Korea Certification — compliant for the South Korean market
• IEC 60947-1 / EN 60947-1: Low-voltage switchgear and controlgear — general rules
• IEC 60947-5 / EN 60947-5: Control circuit devices and switching elements
• IEC/EN 60947-1: Low-voltage switchgear general requirements (harmonized)
• IEC/EN 60947-5: Control circuit devices (harmonized)
• IEC 60068-2-27: Environmental testing — shock
• UL 60335-2-40 LZGH2A2L: UL standard for household and similar electrical appliances — Part 2-40
• UL 508: Standard for industrial control equipment
• CSA C22.2 No.60335-2-40 LZGH2A2L: CSA standard for appliances — Part 2-40
• CSA C22.2 No.14-13: Canadian standard for industrial control equipment
• CSA C22.2 No.60335: Canadian electrical safety standard for appliances
• CSA C22.2 No.14: Canadian standard for industrial control equipment (general)
• CSA: Canadian Standards Association certification
• EN 45555: General methods for the assessment of the ability to recover materials and energy from electrical and electronic equipment
• EN 45555-92: Extended scope assessment for EEE recoverability
• REACH: EU regulation on chemical substances — compliant
• RoHS: Restriction of Hazardous Substances — compliant
• WEEE: Waste Electrical and Electronic Equipment directive — compliant
