ABB 1SAP424100R0001 CI541-DP-XC PROFIBUS Slave 4AI 2AO 8DI 8DO Remote I/O Module

% $-580.75
ABB 1SAP424100R0001 CI541-DP-XC PROFIBUS slave 4AI 2AO 8DI 8DO – Remote I/O Module
ABB 1SAP424100R0001 CI541-DP-XC PROFIBUS slave 4AI 2AO 8DI 8DO – Remote I/O Module

ABB 1SAP424100R0001 CI541-DP-XC PROFIBUS Slave 4AI 2AO 8DI 8DO Remote I/O Module

Brand: ABB
Reference No: 1SAP424100R0001
Catalog No: CI541-DP-XC
Series: Communication interface modules
Tariff Code (HS): 853710
Communication: PROFIBUS DP slave, RS-485
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$580.75

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB CI541-DP-XC (order code 1SAP424100R0001) is a PROFIBUS DP slave interface module for the AC500-XC platform, with 4 analog inputs, 2 analog outputs, 8 digital inputs, and 8 digital outputs built in. It extends with up to 10 additional S500 I/O modules on the same PROFIBUS node, and carries an IP20 rating.

Technical Specifications

Order code 1SAP424100R0001
Type code CI541-DP-XC
Brand ABB
Series AC500-XC Communication interface modules
Function PROFIBUS slave. 4 AI: U, I, RTD. 2 AO: U, I. 8 DI: 24VDC. 8 DO: 24VDC 0.5A
Hardware Interfaces, RS-485 1
Analog Inputs 4
Analog Outputs 2
Number of Digital Inputs 8
Number of Digital Outputs 8
Input Voltage Type DC
Input Voltage 24 V DC
Input Current 5 mA
Delay Time 0.1-32 ms
Output Type Transistor
Output Current 0.5 A
Output Voltage Maximum 20.4-28.8 V
Degree of Protection IP20
Supply Voltage 20.4-28.8 V DC
Ambient Air Temperature, Operation -30C to +70C
Ambient Air Temperature, Storage -40C to +85C
Net Weight 0.139 kg
Dimensions, L x H x W 62 x 76 x 67.5 mm
EAN 4016779866323

Selection Notes

CI541-DP-XC is a PROFIBUS DP slave head module with 14 onboard I/O points (4 AI, 2 AO, 8 DI, 8 DO) and room to extend with up to 10 additional S500 I/O modules on the same PROFIBUS node, so a single drop can grow well past its onboard count. The analog channels accept voltage, current, or RTD signals, which covers both process measurement and temperature inputs without a second module type. Choose a digital-only sibling instead when the application needs more digital I/O and no analog channels at all.

Technical Details

Short Description
PROFIBUS slave interface module: 4 AI, 2 AO, 8 DI, 8 DO, extendable to 10 I/O modules.
Protection Type
IP20
Catalog No
CI541-DP-XC
Delivery Date (Days)
30 days
Model Number
CI541-DP-XC
Tariff Code
853710
