ABB 1SAP415200R0001 TU542-H-XC Hot Swap 24VDC High Current PLC Connection Module

% $-112.13
ABB 1SAP415200R0001 TU542-H-XC Hot Swap high-current I/O terminal unit – PLC Connection Module
ABB 1SAP415200R0001 TU542-H-XC Hot Swap high-current I/O terminal unit – PLC Connection Module

ABB 1SAP415200R0001 TU542-H-XC Hot Swap 24VDC High Current PLC Connection Module

Brand: ABB
Reference No: 1SAP415200R0001
Catalog No: TU542-H-XC
Series: S500 I/O modules
Tariff Code (HS): 853890
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$112.13

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB TU542-H-XC (order code 1SAP415200R0001) is an S500 I/O terminal unit with Hot Swap capability for 24 V DC high-current modules on the AC500-XC platform, using heavier spring terminal contacts than the standard signal-level base. Hot Swap lets the module be replaced without powering down the station or backplane.

Technical Specifications

Order code 1SAP415200R0001
Type code TU542-H-XC
Brand ABB
Series AC500-XC S500 I/O modules
Function For 24 VDC high current modules. Spring terminals. Hot Swap
Degree of Protection IP20
Net Weight 0.165 kg
Gross Weight 0.195 kg
Dimensions, L x H x W 28 x 135 x 67.5 mm
EAN 4013614531767

Selection Notes

TU542-H-XC adds Hot Swap to the 24 V DC high-current I/O terminal base, so a high-current module can be replaced while the rest of the AC500-XC station stays powered. Choose the non-Hot-Swap version instead when the slot has no requirement for online service.

Technical Details

Short Description
S500 I/O terminal unit: 24 V DC high-current modules, spring terminals, Hot Swap.
Mounting Type
Terminal unit
Protection Type
IP20
Catalog No
TU542-H-XC
Delivery Date (Days)
30 days
Model Number
TU542-H-XC
Tariff Code
853890
