ABB 1SAP413200R0001 TU542-XC Spring Terminal 24VDC High Current PLC Connection Module

% $-57.50
ABB 1SAP413200R0001 TU542-XC 24VDC high-current I/O terminal unit – PLC Connection Module
ABB 1SAP413200R0001 TU542-XC 24VDC high-current I/O terminal unit – PLC Connection Module

ABB 1SAP413200R0001 TU542-XC Spring Terminal 24VDC High Current PLC Connection Module

Brand: ABB
Reference No: 1SAP413200R0001
Catalog No: TU542-XC
Series: S500 I/O modules
Tariff Code (HS): 853890
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$57.50

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB TU542-XC (order code 1SAP413200R0001) is an S500 I/O terminal unit for 24 V DC high-current modules on the AC500-XC platform, using heavier spring terminal contacts than the standard signal-level base. It carries an IP20 enclosure rating and does not support Hot Swap of the plugged-in module on this base.

Technical Specifications

Order code 1SAP413200R0001
Type code TU542-XC
Brand ABB
Series AC500-XC S500 I/O modules
Function For 24 VDC high current modules. Spring terminals
Degree of Protection IP20
Net Weight 0.164 kg
Gross Weight 0.194 kg
Dimensions, L x H x W 28 x 135 x 67.5 mm
EAN 4013614529528

Selection Notes

TU542-XC is sized for 24 V DC high-current I/O modules, which need heavier terminal contacts than the standard analog/digital base rated for smaller signal-level currents. It does not support Hot Swap. Choose the Hot Swap variant instead when the high-current module needs to be pulled and replaced without stopping the rest of the station.

Technical Details

Short Description
S500 I/O terminal unit: 24 V DC high-current modules, spring terminals, IP20.
Mounting Type
Terminal unit
Protection Type
IP20
Catalog No
TU542-XC
Delivery Date (Days)
30 days
Model Number
TU542-XC
Tariff Code
853890
