Siemens 6GT2800-5BE00 SIMATIC RF300 RF370T 32 KB FRAM IP68 RFID Transponder

The Siemens 6GT2800-5BE00 RF370T is a 75 x 75 x 41 mm SIMATIC RF300 transponder built for heavier-duty fixtures, with 32765 bytes of FRAM/EEPROM user memory and a 106 kbit/s maximum transfer rate. Its PA12 body mounts flush against metal, is rated IP68 and cULus approved, and is secured with two M5 screws for -25 to +85 degrees C service.

Technical Specifications

Certifications & Standards

• cULus
• EPD

Selection Notes

Same 32765-byte memory as the smaller 50 mm card in the same family, but this transponder's larger 75 x 75 x 41 mm body and heavier M5 fastening give it more mass and read range margin for larger, heavier fixtures where the smaller frame would be undersized. Choose the smaller 50 mm card instead when panel or pallet space is limited and a compact footprint is needed.

Applications

The larger housing suits heavy pallets, molds, and fixtures on RF300 lines where mechanical durability matters as much as the 32765-byte data capacity.
