Siemens 6GF3400-0LT01-7BA1 SIMATIC MV400 External IR Ring Light 24V IP67 Optical Code Reader

% $-1,821.52
Siemens 6GF3400-0LT01-7BA1 External IR Ring Light for SIMATIC MV420 MV440 - 850 nm
Siemens 6GF3400-0LT01-7BA1 External IR Ring Light for SIMATIC MV420 MV440 - 850 nm

Siemens 6GF3400-0LT01-7BA1 SIMATIC MV400 External IR Ring Light 24V IP67 Optical Code Reader

Brand: Siemens
Reference No: 6GF3400-0LT01-7BA1
Catalog No: 6GF3400-0LT01-7BA1
Series: SIMATIC MV420
Tariff Code (HS): 84733020
Stock: 0
Delivery time: 10-15 business day(s)
Shipping Origin: Türkiye EXW
$1,821.52

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Siemens 6GF3400-0LT01-7BA1 is an external infrared ring light for the SIMATIC MV420 and MV440 optical readers, illuminating at 850 nm over a working distance of 500 mm to 3000 mm with a flash duration of up to 10 ms. Its metal housing measures 142 mm in diameter and 43 mm deep, runs on a 24 V supply, and reaches IP67 when mounted with the matching lamp holder.

Technical Specifications

SKU 6GF3400-0LT01-7BA1
Brand Siemens
Series SIMATIC MV400
Product Type Designation Far field ring light, IR 24 V
Product Description External ring light, infrared, 850 nm
Suitability for Use Illumination range 0.5-3 m, flash duration up to 10 ms
Suitability for Operation For mounting with mounting plate 6GF3440-8CD01 on MV440
Housing Material Metal
Color Black
Height 43 mm
Diameter 142 mm
Country of Origin DE
Net Weight 0.556 kg

Selection Notes

This far-field IR ring light reaches 500-3000 mm, so pick it over a close-range or built-in ring light when the MV420 or MV440 is mounted well back from the code, for example on a conveyor with limited headroom. It mounts to the camera housing via the 6GF3440-8CD01 lamp holder rather than directly, so order that mounting plate together with the light if the camera isn't already fitted with it.

Technical Details

Short Description
Siemens 6GF3400-0LT01-7BA1 external IR ring light, 850 nm, 500-3000 mm range, for SIMATIC MV420/MV440.
Mounting Type
Mounting plate 6GF3440-8CD01 (on MV440)
Protection Type
IP67 (with mounting plate)
Catalog No
6GF3400-0LT01-7BA1
Delivery Date (Days)
10-15 days
Model Number
6GF3400-0LT01-7BA1
Tariff Code
84733020
