- Part number
- 6ES7952-1KT00-0AA0
Siemens has announced the end of 6ES7952-1KT00-0AA0
Once production ends, supply depends on remaining stock.
No replacement announced yet. Tell us the application and we will propose an alternative.
SIMATICSiemens 6ES7952-1KT00-0AA0 SIMATIC S7-400 Memory Card 32 MB Flash-EPROM PLC Memory Card
SIMATIC memory card for S7-400 CPUs, 32 MB, 5V Flash-EPROM, long design, 53 g.
Description
About the 6ES7952-1KT00-0AA0
About the 6ES7952-1KT00-0AA0
The Siemens 6ES7952-1KT00-0AA0 is a SIMATIC memory card for the S7-400 CPU family, built as a long-design 5V Flash-EPROM card with 32 Mbyte capacity. It plugs into the S7-400 CPU's memory card slot to hold the user program, block data and configuration. At 53 g, it is a field-swappable card for loading a program onto a new CPU or transferring it between S7-400 stations.
Selection Notes
This 32 Mbyte card sits between the smaller and larger long-design S7-400 cards: pick it over the 16 Mbyte version when the program plus retentive data no longer fits with headroom, and step up to the 64 Mbyte card instead if future expansion of the program or recipe data is planned.
Specification
Full specification
Version Classification 4
| eClass | 16 27-24-22-12 |
|---|---|
| ETIM | 10 EC000192 |
| IDEA | 4 6458 |
| UNSPSC | 15 43-20-14-02 |
Approvals / Certificates 2
| General Product Approval Miscellaneous | For use in hazard- |
|---|---|
| General Product Approval EMV | ous locations |
Show all 21 specifications ↓ Show less ↑15 more values in Identification, Logistics.
Identification 9
| Part number | 6ES7952-1KT00-0AA0 |
|---|---|
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Phase-out announced by the manufacturer |
| EAN | 4019169010023 |
| ETIM class | EC000192 |
| eCl@ss | 27242212 |
Logistics 6
| Net weight | 0.053 kg |
|---|---|
| Country of origin | DE |
| Shipping weight | 0.553 kg |
| Ships from | Türkiye |
| Dispatch | — |
| Stock | On request |
Source: manufacturer data · Last verified: 01 Nov 2026
Documents
Documents for 6ES7952-1KT00-0AA0
No documents are on file for this part yet.
Ask us for the datasheet
Quick answers
Questions about the 6ES7952-1KT00-0AA0
What is the HS code of 6ES7952-1KT00-0AA0 for customs?
The tariff (HS) code on file for 6ES7952-1KT00-0AA0 is 85235110.
What is the EAN of 6ES7952-1KT00-0AA0?
The EAN (GTIN) of 6ES7952-1KT00-0AA0 is 4019169010023.
Where does 6ES7952-1KT00-0AA0 ship from, and how fast?
6ES7952-1KT00-0AA0 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival.
