SIMATICSiemens 6ES7952-1AL00-0AA0 SIMATIC S7-400 RAM Memory Card 2MB PLC Memory Card
SIMATIC S7-400 RAM memory card, long design, 2 MB, 58g
Description
About the 6ES7952-1AL00-0AA0
About the 6ES7952-1AL00-0AA0
The Siemens SIMATIC S7 RAM memory card (6ES7952-1AL00-0AA0) is a long-design load memory module for the S7-400 rack, offering 2 MB of RAM capacity at 58 g weight. It plugs into the CPU memory card slot to hold the user program and requires battery backup to retain data when powered down.
Selection Notes
This is a RAM card, not a flash card, so it depends on the CPU's battery backup to retain the program when powered down, unlike the flash memory cards used on newer SIMATIC CPU families. The long design fits S7-400 CPUs that take the longer card format rather than the short card slot, so confirm the CPU's card format before ordering. 2 MB covers small to mid-size S7-400 programs; larger programs need a higher-capacity card.
Applications
Load memory for SIMATIC S7-400 CPUs that use the long-format RAM card, for initial program storage during commissioning or as a replacement for an existing S7-400 memory card.
Specification
Full specification
Version Classification 4
| eClass | 16 27-24-22-12 |
|---|---|
| ETIM | 10 EC000192 |
| IDEA | 4 6458 |
| UNSPSC | 15 43-20-14-02 |
Approvals / Certificates 2
| General Product Approval Miscellaneous | For use in hazard- |
|---|---|
| General Product Approval EMV | ous locations |
Show all 21 specifications ↓ Show less ↑15 more values in Identification, Logistics.
Identification 9
| Part number | 6ES7952-1AL00-0AA0 |
|---|---|
| Brand | Siemens |
| Condition | New, factory sealed |
| Source | Siemens and its authorised distributors |
| Warranty | Manufacturer warranty |
| Lifecycle status | Phase-out announced by the manufacturer |
| EAN | 4019169009935 |
| ETIM class | EC000192 |
| eCl@ss | 27242212 |
Logistics 6
| Net weight | 0.058 kg |
|---|---|
| Country of origin | DE |
| Shipping weight | 0.558 kg |
| Ships from | Türkiye |
| Dispatch | 13 Nov |
| Stock | Low stock |
Source: manufacturer data · Last verified: 01 Nov 2026
Documents
Documents for 6ES7952-1AL00-0AA0
No documents are on file for this part yet.
Ask us for the datasheet
Quick answers
Questions about the 6ES7952-1AL00-0AA0
What is the HS code of 6ES7952-1AL00-0AA0 for customs?
The tariff (HS) code on file for 6ES7952-1AL00-0AA0 is 85235110.
What is the EAN of 6ES7952-1AL00-0AA0?
The EAN (GTIN) of 6ES7952-1AL00-0AA0 is 4019169009935.
Where does 6ES7952-1AL00-0AA0 ship from, and how fast?
6ES7952-1AL00-0AA0 ships from Türkiye. Shipping calculated at checkout · import duties and taxes paid on arrival. Stock items are dispatched within 1–2 business days.
