SIMATIC S7-1500

Siemens 6ES7541-1AB00-0AB0 SIMATIC S7-1500 CM PtP RS422/485 HF 115.2 kbit/s Communication Module

SIMATIC S7-1500 CM PtP RS422/485 HF module, 115.2 kbit/s, Modbus RTU master/slave, 1200 m reach.

Communication
RS422, RS485, Freeport, 3964(R), USS, Modbus RTU master/slave
EAN
4025515079941
Description

About the CM PtP RS 422 / 485 HF

The Siemens 6ES7541-1AB00-0AB0 is a SIMATIC S7-1500 CM PtP RS422/485 HF point-to-point communication module for RS422 and RS485 serial links up to 115.2 kbit/s over a 15-pin D-sub socket, supporting Freeport, 3964(R), USS, and Modbus RTU master/slave protocols. It draws 43 mA from the backplane bus and mounts directly on the S7-1500 rail alongside the CPU.

Selection Notes

The HF designation supports 115.2 kbit/s over RS422 or RS485, well above the throughput of the base-level PtP modules in the same product line, and the 4-wire full-duplex RS422 wiring together with RS485 multidrop lets one module reach up to 1 200 m of cable. Modbus RTU master mode addresses up to 32 devices, 1 to 247 with extended addressing to 65535, so this module fits multidrop RS485 networks of Modbus field instruments where a single RS232 point-to-point link would not scale. The 8 kbyte telegram buffer holds more queued 3964(R) or Freeport frames during bursts than a smaller-buffer module handles.

Applications

Multidrop RS485 sensor and actuator networks, Modbus RTU polling of drives or metering devices, and long-distance RS422 links between control cabinets up to 1 200 m, all addressed through the S7-1500 backplane without a separate gateway.

Specification

Full specification

67 values · Last verified 01 Nov 2026

General information 7

Product type designation CM PtP RS 422 / 485 HF
Product function: I&M data Yes; I&M 0
Product function: Fast startup Yes
Engineering with: STEP 7 TIA Portal configurable/integrated from version V12 / V12
Engineering with: STEP 7 configurable/integrated from version V5.5 SP2 with GSD file
Engineering with: PROFIBUS from GSD version/GSD revision -/-
Engineering with: PROFINET from GSD version/GSD revision V2.3 / -

Installation type/mounting 1

Rail mounting Yes; S7-1500 mounting rail

Input current 1

Current consumption (rated value) 43 mA; From the backplane bus
Show all 67 specifications ↓ Show less ↑58 more values in Identification, Power, Power loss, Address area, Interface types, Protocols, Interrupts/diagnostics/status information, Potential separation, Isolation, Ambient conditions, Decentralized operation, Dimensions, Weights, EClass 7.1 27-24-22-08, For use in hazardous locations, Logistics.

Identification 8

Part number 6ES7541-1AB00-0AB0
Type designation CM PtP RS 422 / 485 HF
Brand Siemens
Condition New, factory sealed
Source Siemens and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Phase-out announced by the manufacturer
EAN 4025515079941

Power 1

Power consumption from the backplane bus 0.65 W

Power loss 1

Power loss, typ. 0.6 W

Address area 1

Address space per module: Inputs 8 byte

Interface types 6

RS 485: Transmission rate, max. 115.2 kbit/s
RS 485: Cable length, max. 1 200 m
RS 422: Transmission rate, max. 115.2 kbit/s
RS 422: Cable length, max. 1 200 m
RS 422: 4-wire full duplex connection Yes
RS 422: 4-wire multipoint connection No

Protocols 9

Integrated protocols Freeport: Telegram length, max. 4 kbyte
Integrated protocols Freeport: Bits per character 7 or 8
Integrated protocols Freeport: Number of stop bits 1 or 2 bit
Integrated protocols Freeport: Parity 3964 (R) None, even, odd, always 1, always 0, any
Integrated protocols Freeport: Parity Modbus RTU master None, even, odd, always 1, always 0, any
Integrated protocols Freeport: Address area 1 to 247, extended 1 to 65535
Integrated protocols Freeport: max. number of devices Modbus RTU device 32
Telegram buffer: Buffer memory for telegrams 8 kbyte
Telegram buffer: Number of telegrams which can be buffered 255

Interrupts/diagnostics/status information 8

Diagnostics function Yes
Alarms: Diagnostic alarm Yes
Alarms: Hardware interrupt No
Diagnoses: Wire break Yes
Diagnostics indication LED: RUN LED Yes; green LED
Diagnostics indication LED: ERROR LED Yes; red LED
Diagnostics indication LED: Receive RxD Yes; Yellow LED
Diagnostics indication LED: Transmit TxD Yes; Yellow LED

Potential separation 1

between backplane bus and interface Yes

Isolation 1

Isolation tested with 707 V DC (type test)

Ambient conditions 3

Ambient temperature during operation: horizontal installation, min. 0 °C
Ambient temperature during operation: vertical installation, min. 0 °C
Altitude during operation relating to sea level: Installation altitude above sea level, max. 5 000 m; restrictions for installation altitudes > 2 000 m, see ET 200MP system manual

Decentralized operation 4

to SIMATIC S7-300 Yes
to SIMATIC S7-400 Yes
to SIMATIC S7-1500 Yes
to standard PROFINET controller Yes

Dimensions 3

Width 35 mm
Height 147 mm
Depth 127 mm

Weights 1

Weight, approx. 0.22 kg

EClass 7.1 27-24-22-08 4

eClass 6 27-24-22-08
ETIM 10 EC001423
IDEA 4 3564
UNSPSC 15 32-15-17-05

For use in hazardous locations 1

FM CCC-Ex Type Examination Cer- tificate

Logistics 6

Net weight 0.268 kg
Country of origin DE
Shipping weight 0.768 kg
Ships from Türkiye
Dispatch —
Stock On request

Source: manufacturer data · Last verified: 01 Nov 2026
