Part number
6ES7540-1AB00-0AA0
Model no
CM PtP RS 422 / 485 BA
$775.22 Critical stock Dispatch Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days. · From Türkiye
Manufacturer phase-out

Siemens has announced the end of 6ES7540-1AB00-0AA0

Once production ends, supply depends on remaining stock.

No replacement announced yet. Tell us the application and we will propose an alternative.

SIMATIC S7-1500

Siemens 6ES7540-1AB00-0AA0 SIMATIC S7-1500 CM PtP RS422/485 BA 19.2kbit/s PLC Communication Module

SIMATIC S7-1500 CM PtP RS422/485 BA, serial communication module, 19.2kbit/s, Freeport/3964(R)/USS

Communication
RS422, RS485, Freeport, 3964(R), USS, PROFINET GSD V2.3
EAN
4025515079934
Description

About the CM PtP RS 422 / 485 BA

The Siemens 6ES7540-1AB00-0AA0 is a SIMATIC S7-1500 point-to-point communication module, type CM PtP RS422/485 BA, providing an RS422/RS485 serial interface on a 15-pin D-sub socket. It transmits at up to 19.2 kbit/s over cable runs up to 1 200 m and supports Freeport, 3964(R), and USS protocols for connecting third-party serial devices.

Selection Notes

USS protocol support lets this module poll Siemens drives (such as MICROMASTER or SINAMICS units with USS interfaces) directly over RS485 without a PROFIBUS or PROFINET gateway, which is the main reason to pick a CM PtP module over a fieldbus communication module for small serial-drive networks. Freeport mode gives the user program full control of the telegram format for connecting non-Siemens serial instruments (scales, barcode readers, third-party controllers), while 3964(R) provides a fixed handshake protocol for point-to-point links to other SIMATIC controllers. At 19.2 kbit/s and 1 200 m maximum cable length, throughput is adequate for polling or parameter read/write but not for high-speed data acquisition.

Applications

Serial point-to-point links to third-party instrumentation, barcode scanners, or older SIMATIC S7-300/S7-400/S7-1500 stations, and USS-based polling of Siemens drives without a fieldbus network.

Specification

Full specification

64 values · Last verified 01 Nov 2026

General information 7

Product type designation CM PtP RS 422 / 485 BA
Product function: I&M data Yes; I&M 0
Product function: Fast startup Yes
Engineering with: STEP 7 TIA Portal configurable/integrated from version V12 / V12
Engineering with: STEP 7 configurable/integrated from version V5.5 SP2 with GSD file
Engineering with: PROFIBUS from GSD version/GSD revision -/-
Engineering with: PROFINET from GSD version/GSD revision V2.3

Installation type/mounting 1

Rail mounting Yes; S7-1500 mounting rail

Input current 1

Current consumption (rated value) 43 mA; From the backplane bus
Show all 64 specifications ↓ Show less ↑55 more values in Identification, Power, Power loss, Address area, Interface types, Protocols, Interrupts/diagnostics/status information, Potential separation, Isolation, Ambient conditions, Decentralized operation, Dimensions, Weights, ETIM 7 EC001423, General Product Approval For use in hazardous locations, For use in hazard-Maritime application ous locations, Logistics.

Identification 8

Part number 6ES7540-1AB00-0AA0
Type designation CM PtP RS 422 / 485 BA
Brand Siemens
Condition New, factory sealed
Source Siemens and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Phase-out announced by the manufacturer
EAN 4025515079934

Power 1

Power consumption from the backplane bus 0.65 W

Power loss 1

Power loss, typ. 0.6 W

Address area 1

Address space per module: Inputs 8 byte

Interface types 6

RS 485: Transmission rate, max. 19.2 kbit/s
RS 485: Cable length, max. 1 200 m
RS 422: Transmission rate, max. 19.2 kbit/s
RS 422: Cable length, max. 1 200 m
RS 422: 4-wire full duplex connection Yes
RS 422: 4-wire multipoint connection No

Protocols 7

Integrated protocols Freeport: Telegram length, max. 1 kbyte
Integrated protocols Freeport: Bits per character 7 or 8
Integrated protocols Freeport: Number of stop bits 1 or 2 bit
Integrated protocols Freeport: Parity 3964 (R) None, even, odd, always 1, always 0, any
Integrated protocols Freeport: Parity None, even, odd, always 1, always 0, any
Telegram buffer: Buffer memory for telegrams 2 kbyte
Telegram buffer: Number of telegrams which can be buffered 255

Interrupts/diagnostics/status information 8

Diagnostics function Yes
Alarms: Diagnostic alarm Yes
Alarms: Hardware interrupt No
Diagnoses: Wire break Yes
Diagnostics indication LED: RUN LED Yes; green LED
Diagnostics indication LED: ERROR LED Yes; red LED
Diagnostics indication LED: Receive RxD Yes; Yellow LED
Diagnostics indication LED: Transmit TxD Yes; Yellow LED

Potential separation 1

between backplane bus and interface Yes

Isolation 1

Isolation tested with 707 V DC (type test)

Ambient conditions 3

Ambient temperature during operation: horizontal installation, min. 0 °C
Ambient temperature during operation: vertical installation, min. 0 °C
Altitude during operation relating to sea level: Installation altitude above sea level, max. 5 000 m; restrictions for installation altitudes > 2 000 m, see ET 200MP system manual

Decentralized operation 4

to SIMATIC S7-300 Yes
to SIMATIC S7-400 Yes
to SIMATIC S7-1500 Yes
to standard PROFINET controller Yes

Dimensions 3

Width 35 mm
Height 147 mm
Depth 127 mm

Weights 1

Weight, approx. 0.22 kg

ETIM 7 EC001423 2

IDEA 4 3564
UNSPSC 15 32-15-17-05

General Product Approval For use in hazardous locations 1

China RoHS FM

For use in hazard-Maritime application ous locations 1

CCC-Ex NK / Nippon Kaiji Ky- okai

Logistics 6

Net weight 0.268 kg
Country of origin DE
Shipping weight 0.768 kg
Ships from Türkiye
Dispatch 18 Nov
Stock Critical stock

Source: manufacturer data · Last verified: 01 Nov 2026
