Part number
6ES7521-1FH00-0AA0
Model no
DI 16x230VAC BA
$313.61 Critical stock Dispatch Planned dispatch date. We aim to ship within 1 business day. Depending on warehouse workload it can take 2–3 business days. · From Türkiye
SIMATIC S7-1500

Siemens 6ES7521-1FH00-0AA0 SIMATIC S7-1500 DI 16x230VAC BA 16-Channel PLC I/O Module

SIMATIC S7-1500 DI 16x230VAC BA, 16-channel digital input module, 120/230V AC, groups of 4

Rated operational voltage
120–230 V AC
EAN
4025515080244
Description

About the DI 16x230VAC BA

The Siemens 6ES7521-1FH00-0AA0 is a SIMATIC S7-1500 digital input module, type DI 16x230VAC BA, providing 16 AC inputs rated 120/230 V AC in groups of four. Input delay is 25 ms and the module reads IEC 61131 type 1 signal levels, with 0 to 40 V AC read as signal 0 and 79 to 264 V AC read as signal 1. Front connectors are ordered separately.

Selection Notes

The 79 to 264 V AC signal-1 window and 120/230 V AC rating make this module suitable for reading mains-voltage field devices directly, without an interposing relay, where DC I/O modules cannot be used. Channels are isolated in groups of 4, so a fault or short on one group does not propagate to the other three groups on the same module. The 25 ms input delay filters contact bounce and AC ripple, which is standard for this signal class but not suited to fast pulse counting; a DC input module should be used where sub-millisecond response is required. Front connectors (screw-terminal or push-in) are not included and must be ordered separately.

Applications

Reading 230 V AC field signals such as limit switches, pushbuttons, and relay contacts directly into an S7-1500 station without signal conversion, in cabinets where mains-voltage field wiring is standard practice.

Specification

Full specification

78 values · Last verified 01 Nov 2026

General information 14

Product type designation DI 16x230VAC BA
HW functional status FS01
Firmware version V2.0.0
FW update possible Yes
Product function: I&M data Yes; I&M0 to I&M3
Product function: Isochronous mode No
Product function: Prioritized startup Yes
Engineering with: STEP 7 TIA Portal configurable/integrated from version V12 / V12
Engineering with: STEP 7 configurable/integrated from version V5.5 SP3 / -
Engineering with: PROFIBUS from GSD version/GSD revision V1.0 / V5.1
Engineering with: PROFINET from GSD version/GSD revision V2.3 / -
Operating mode: DI Yes
Operating mode: Counter No
Operating mode: MSI Yes

Power 1

Power consumption from the backplane bus 1 W

Power loss 1

Power loss, typ. 4.9 W
Show all 78 specifications ↓ Show less ↑62 more values in Identification, Digital inputs, Encoder, Interrupts/diagnostics/status information, Potential separation, Permissible potential difference, Isolation, Standards, approvals, certificates, Security, Ambient conditions, Dimensions, Weights, Version Classification, General Product Approval, Logistics.

Identification 10

Part number 6ES7521-1FH00-0AA0
Type designation DI 16x230VAC BA
Brand Siemens
Condition New, factory sealed
Source Siemens and its authorised distributors
Warranty Manufacturer warranty
Lifecycle status Active, in production
EAN 4025515080244
ETIM class EC001419
eCl@ss 27242204

Digital inputs 11

Number of digital inputs 16
Digital inputs, parameterizable No
Sourcing/sinking input P-reading
Input characteristic curve in accordance with IEC 61131, type 1 Yes
Input voltage: Rated value (AC) 230 V; 120/230 V AC, 50/60 Hz
Input voltage: for signal "0" 0V AC to 40V AC
Input voltage: for signal "1" 79V AC to 264V AC
Input current: for signal "1", typ. 11 mA; At 230 V AC and 5.5 mA at 120 V AC
Input delay (for rated value of input voltage) for standard inputs: parameterizable No
Cable length: shielded, max. 1 000 m
Cable length: unshielded, max. 600 m

Encoder 2

Connectable encoders: 2-wire sensor Yes
Connectable encoders: permissible quiescent current (2-wire sensor), max. 2 mA

Interrupts/diagnostics/status information 12

Diagnostics function No
Alarms: Diagnostic alarm No
Alarms: Hardware interrupt No
Diagnoses: Monitoring the supply voltage No
Diagnoses: Wire break No
Diagnoses: Short-circuit No
Diagnostics indication LED: RUN LED Yes; green LED
Diagnostics indication LED: ERROR LED Yes; red LED
Diagnostics indication LED: Monitoring of the supply voltage (PWR-LED) No
Diagnostics indication LED: Channel status display Yes; green LED
Diagnostics indication LED: for channel diagnostics No
Diagnostics indication LED: for module diagnostics Yes; red LED

Potential separation 3

Potential separation channels: between the channels No
Potential separation channels: between the channels, in groups of 4
Potential separation channels: between the channels and backplane bus Yes

Permissible potential difference 1

between different circuits 250 V AC between the channels and the backplane bus; 500 V AC between the channels

Isolation 1

Isolation tested with 3 100 V DC

Standards, approvals, certificates 1

Suitable for safety functions No

Security 2

signed firmware update No
data integrity No

Ambient conditions 2

Ambient temperature during operation: horizontal installation, min. 0 °C
Ambient temperature during operation: vertical installation, min. 0 °C

Dimensions 3

Width 35 mm
Height 147 mm
Depth 129 mm

Weights 1

Weight, approx. 300 g

Version Classification 4

eClass 16 27-24-22-04
ETIM 10 EC001419
IDEA 4 3566
UNSPSC 15 32-15-17-05

General Product Approval 3

Miscellaneous Manufacturer Declara-tion For use in hazard-
General Product Approval ous locations
China RoHS Manufacturer Declara- FM tion

Logistics 6

Net weight 0.332 kg
Country of origin DE
Shipping weight 0.832 kg
Ships from Türkiye
Dispatch 18 Nov
Stock Critical stock

Source: manufacturer data · Last verified: 01 Nov 2026
